B&R 8LSAA4.D8045S200-3 400VAC 4500RPM 2.8Nm Servo Motor with 3.2Nm Brake

The B&R 8LSAA4.D8045S200-3 is a 400 VAC synchronous servo motor designed for compact machine axes that require single-turn absolute feedback and a holding brake.

This motor operates at a nominal speed of 4500 rpm and delivers 2.800 Nm nominal torque. Its smooth 14 mm shaft is suitable for clamping couplings, friction-locking hubs, and accurately aligned direct-drive assemblies.

The integrated 3.20 Nm holding brake is intended to retain a stopped axis after drive power is removed. This configuration is suitable for compact vertical mechanisms, transfer modules, indexed fixtures, and machine sections where uncontrolled shaft movement is not acceptable.

The ECI 1119 FS EnDat 2.2 single-turn encoder provides position feedback for compatible servo drive systems. Before replacement, confirm the motor model, encoder type, shaft design, brake requirement, flange size, and centering dimensions.

This product is a synchronous servo motor only. It should not be described as an internal I/O module, X2X Link component, power supply, PLC, or servo amplifier.

Key Features

400 VAC synchronous servo motor

4500 rpm nominal speed

2.800 Nm nominal torque

3.200 Nm stall torque

3.20 Nm holding brake

EnDat 2.2 single-turn encoder

Smooth 14 mm shaft

70 mm square flange

60 mm centering diameter

Self-cooled construction

Compact servo motor format

Typical Applications

Packaging machinery

Compact vertical axes

Servo-driven transfer units

Rotary indexing equipment

Assembly machinery

Labeling systems

Printing and converting machines

Industrial servo motor replacement projects

Installation Notes

Confirm the original motor model, encoder type, brake requirement, shaft diameter, flange size, and centering diameter before replacement.

The holding brake is designed to keep a stationary axis in position. It should not be used as the primary method for repeated dynamic braking.

Use a compatible servo drive and verify encoder wiring, brake wiring, cable type, and machine parameter settings before commissioning.

FAQ

Q

Does 8LSAA4.D8045S200-3 include a holding brake

A

Yes it includes a 3.20 Nm holding brake

Q

What feedback device does this motor use

A

It uses an ECI 1119 FS EnDat 2.2 single-turn encoder

Q

Is the shaft smooth or keyed

A

It has a smooth 14 mm shaft without oil seal

Q

What is the nominal speed

A

The nominal speed is 4500 rpm

Q

What is the nominal torque

A

The nominal torque is 2.800 Nm
