B&R X20 PLC B&R X20CP3686X For Power Link Controller System, good quality

Product Details

Place of Origin: Austira or China as original

Brand Name: B&R

Certification: CE UL cURus E360421 Servo and stepper motors - Component

Model Number: X20 PLC x20cp3686X

Payment & Shipping Terms

Minimum Order Quantity: 1 piece

Price: USD 500 -20000 piece as depend on booking price

Packaging Details: 100*550*35 CM

Delivery Time: 3-70 working days

Payment Terms: D/A, D/P, T/T, Western Union

Supply Ability: 5 sets 10 days

Get Best Price
Contact Now
Specifications
Highlight:
Brand:
B&r X20CP3686X
Part Number:
X20cp3686X B&r
Nominal Speed NN [rpm:
X20 Plc X20cp3684
Maximum Speed Nmax [rpm:
Synch Motor
Maximum Torque Mmax [Nm:
X20cp3686X
Brand:
B&r X20CP3686X
Part Number:
X20cp3686X B&r
Nominal Speed NN [rpm:
X20 Plc X20cp3684
Maximum Speed Nmax [rpm:
Synch Motor
Maximum Torque Mmax [Nm:
X20cp3686X
Description
B&R X20 PLC B&R X20CP3686X For Power Link Controller System, good quality



B&R X20PLC X20CP3686X:

DESCRIPTION:



  • Intel Atom 1.3 GHz performance with integrated I/O processor
  • Ethernet, POWERLINK V2 with poll-response chaining and onboard USB
  • 3 slots for modular interface expansion
  • 1 GB LPDDR4 SDRAM
  • 2 GB onboard flash drive
  • CompactFlash as removable application memory
  • Controller redundancy possible
  • Fanless

Introducing the new X20 controller X203686X, the latest addition to our product family designed to meet the highest performance requirements. Powered by Intel Atom processor technology, this controller boasts a 1.3 GHz performance with integrated I/O processor, making it the perfect choice for applications that demand top-notch speed and reliability.

Equipped with a basic configuration that includes USB, Ethernet, POWERLINK V2, and removable CompactFlash, the X20CP3686X sets itself apart with its standard gigabit communication on the Ethernet interface. Additionally, the onboard POWERLINK interface supports the poll-response chaining mode (PRC) for even more real-time network performance.

One of the standout features of the X20 controller is its modular interface expansion, with 3 slots available for custom configuration and connectivity options. This flexibility allows users to tailor the controller to their specific needs, ensuring seamless integration with existing systems.

In terms of memory and storage, the X20 controller comes with 1 GB LPDDR4 SDRAM and a 2 GB onboard flash drive, providing ample resources for running complex applications and storing critical data. The removable CompactFlash adds another layer of versatility, allowing for easy application memory management.

Despite its powerful performance, the X20 controller offers controller redundancy and a fanless design, ensuring reliable operation in any environment. This makes it an ideal choice for applications where downtime is not an option.

Overall, the X20 controller combines cutting-edge technology with robust features to deliver outstanding performance and versatility. Whether it's for industrial automation, machine control, or any other high-demand application, the X20 controller is poised to meet and exceed expectations.

With its Intel Atom processor technology, advanced networking capabilities, and modular expansion options, the X20 controller is a top-tier solution for applications with the most demanding performance requirements. Experience the power and flexibility of the X20 controller and elevate your systems to new heights of efficiency and reliability.

B&R X20 PLC B&R X20CP3686X For Power Link Controller System, good quality 0

B&R X20PLC (Others)

x20cp1584
x20cp1585
x20cp1686x
x20cp3584
x20cp3685
x20cp3686x
x20cp3687x
x20cp3684
x20cp3584
x20cp3685
Controller
CompactFlash slot 1
Real-time clock Nonvolatile, resolution 1 s, -20 to 20 ppm accuracy at 25°C
FPU Yes
Processor
Type Atom E3930
Clock frequency 1.3 GHz
L1 cache
Data code 24 kB
Program code 32 kB
L2 cache 1 MB
Integrated I/O processor Processes I/O data points in the background
Modular interface slots 3
Remanent variables Max. 1 MB
Shortest task class cycle time 100 µs
Typical instruction cycle time 0.0015 µs
Data buffering
Battery monitoring Yes
Lithium battery During operation: 4 years
PLC switched off: Min. 2 years at 23°C ambient temperature
Standard memory
RAM 1 GB LPDDR4 SDRAM
User RAM 1 MB SRAM
Application memory
Type 2 GB eMMC flash memory
Data retention 10 years
Writable data amount
Guaranteed 40 TB
Results for 5 years 21.9 GB/day
Guaranteed erase/write cycles 20,000
Error-correcting code (ECC) Yes
