The model 6SL3120-1TE24-5AA3 is a high-performance servo drive module engineered to deliver precision motion control, energy efficiency, and long-term reliability in demanding industrial environments. Designed for seamless integration into modern automation systems, this motor module is widely used in applications such as packaging systems, textile machinery, plastics processing, and material handling equipment.
Technical Specifications
| Parameter | Specification |
|---|
| Product Series | S120-Compatible Drive System |
| Input Voltage | 600V DC |
| Output Voltage | 3-phase AC 400V |
| Output Current | 45A |
| Power Rating | 11 kW (continuous), 15 kW (peak) |
| Structure | Compact book-size design with internal air cooling |
| Control Interface | DRIVE-CLiQ compatible |
| Safety Features | Integrated safety functions (up to SIL 3 level) |
| Communication Protocols | PROFIBUS DP, PROFINET, Ethernet/IP |
| Dimensions (W × H × D) | 150 mm × 250 mm × 180 mm |
| Weight | 9.4 kg |
| Operating Temperature | 0°C to 40°C |
| Protection Rating | IP20 |
Key Features
High-Precision Motion Control
This servo drive utilizes advanced vector control technology to ensure smooth and accurate motor operation, even under rapidly changing loads. With encoder feedback support, it enables highly accurate positioning suitable for precision automation tasks.
Energy-Efficient Operation
Optimized modulation techniques help reduce harmonic distortion and improve overall energy efficiency. The regenerative braking feature allows excess energy to be fed back into the system, reducing power consumption and operating costs.
Integrated Safety Functions
Built-in safety capabilities, including Safe Torque Off (STO) and Safe Stop 1 (SS1), support compliance with international safety standards. The system is suitable for applications requiring high safety performance levels.
Compact and Modular Design
The book-size structure allows efficient use of cabinet space. The modular architecture simplifies system expansion and supports flexible multi-axis configurations.
Advanced Diagnostics and Monitoring
The drive includes comprehensive diagnostic tools for real-time monitoring, fault analysis, and predictive maintenance. This helps reduce downtime and improves system reliability.
Typical Applications
This servo drive module is ideal for industries requiring accurate and reliable motion control, including:
- Packaging systems: filling, labeling, conveying
- Textile machinery: weaving and spinning equipment
- Plastics processing: injection molding and extrusion
- Material handling: robotic systems and automated conveyors
- CNC and precision machining systems
Key Advantages
- Scalable Architecture: Supports multi-axis configurations for complex automation systems
- Reliable Performance: Designed for stable operation in industrial environments
- Flexible Integration: Compatible with common industrial communication protocols
- Reduced Maintenance: Built-in diagnostics and efficient cooling system extend service life
Installation and Maintenance
Installation
The module requires a 600V DC power supply and is designed for cabinet installation. It supports standard mounting methods and integrates easily with compatible control systems.
Maintenance
Routine inspection of cooling components and connection interfaces is recommended. Firmware updates can be performed via network connection to maintain optimal performance.
Summary
The 6SL3120-1TE24-5AA3 servo drive module offers a powerful combination of precision control, energy efficiency, and robust design. It is a reliable solution for modern industrial automation systems, helping improve productivity and reduce operational costs across a wide range of applications.
For detailed technical documentation, refer to official product manuals or authorized distributors.
