B&R X20CP0482 Compact-S PLC 300MHz 128MB RAM

The B&R X20CP0482 is an entry-level Compact-S PLC designed for small and cost-sensitive machine automation applications. Its 300 MHz ARM Cortex-A9 processor works with a dedicated I/O processor, allowing cyclic I/O processing to run independently from the main application.

Compared with the X20CP0483 and X20CP0484, the X20CP0482 has lower processing performance, RAM and remanent memory. Its advantage is a compact, fanless and battery-free architecture for machines that do not require large programs or extensive data processing.

Key Features

• 300 MHz ARM Cortex-A9 processor
• 128 MB DDR3 RAM and 1 GB onboard flash
• 16 kB FRAM for remanent variables
• Integrated Ethernet, POWERLINK, USB and X2X Link
• Selectable Compact-S base with up to two interface slots
• Fanless and battery-free design

Typical Applications

• Small packaging machines
• Conveyor and material-handling systems
• Compact assembly stations
• Simple POWERLINK motion systems
• Standalone machine control panels

FAQ

Q: What is the main difference between X20CP0482 and X20CP0483?

A: The X20CP0482 uses a 300 MHz processor with 128 MB RAM and 16 kB FRAM. The X20CP0483 increases these specifications to 500 MHz, 256 MB RAM and 32 kB FRAM.

Q: Is a Compact-S base included with the CPU?

A: No. A compatible X20BB5x, X20BB6x or X20BB7x base, an X20PS9600 or X20PS9602 power supply module and an X20TB12 terminal block must be selected separately.

Q: Can the X20CP0482 communicate with B&R ACOPOS drives?

A: Yes. Its onboard POWERLINK V2 interface supports integration with compatible ACOPOS servo drive systems.
