B&R X20CP1585 Compact PLC CPU Controller with Ethernet POWERLINK and USB Interface

The B&R X20CP1585 is a compact PLC CPU controller designed for industrial automation systems based on the X20 control platform.

It provides real-time control processing for machine automation applications and supports distributed I/O expansion through the X20 system architecture. The controller integrates Ethernet-based communication and POWERLINK fieldbus technology for deterministic industrial networking.

With a modular and scalable design, the X20CP1585 is suitable for a wide range of automation tasks including machine control, production systems, and process automation environments.

The unit is designed for DIN rail installation inside industrial control cabinets and operates as the central processing unit of the automation system.

Key Features

Compact PLC CPU controller for X20 system
Real-time industrial automation control
Integrated Ethernet and POWERLINK communication
USB programming and service interface
Modular X20 I/O expansion support
Fanless industrial design (no cooling fan)
High-speed deterministic control performance
DIN rail mounted controller module
Stable long-term industrial operation
IP20 protection for cabinet installation

Typical Applications

Industrial machine automation
Packaging machinery control systems
Conveyor systems
Production line automation
Process control systems
Material handling systems
Factory automation cabinets

Installation Notes

The X20CP1585 must be installed on a DIN rail inside a control cabinet. Ensure stable 24 VDC power supply and proper grounding.

Use compatible X20 I/O modules for system expansion. Configure POWERLINK communication settings before commissioning.

FAQ

Q: Is X20CP1585 a PLC CPU or an I/O module?
A: It is a PLC CPU controller.

Q: Does it support Ethernet communication?
A: Yes, it supports industrial Ethernet and POWERLINK.

Q: Can it be expanded with I/O modules?
A: Yes, it is fully compatible with B&R X20 I/O system.

Q: Does it require cooling fan?
A: No, it uses fanless passive cooling.
