Allen Bradley MPL-B430P-MJ72AA Low Inertia Servo Motor with High Output Brushless Design 5000 RPM 2.2 kW Output Power

Name: Allen Bradley MPL-B430P-MJ72AA Low Inertia Servo Motor with High Output Brushless Design 5000 RPM 2.2 kW Output Power
Brand: AB
SKU: MPL-B430P-MJ72AA
Rating: 4.8 (178 reviews)

Product Details

Place of Origin: USA

Brand Name: AB

Certification: IOS9100

Model Number: MPL-B430P-MJ72AA

Payment & Shipping Terms

Minimum Order Quantity: 1 Piece

Payment Terms: D/A, D/P, T/T, Western Union

Supply Ability: 10 Pieces / 30 days

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:

Shaft Diameter:	5/8 Inch	Gross Weight:	220g
Interface:	PowerLink	Torque:	21g.cm
Frequency:	50HZ, 60HZ	Horsepower:	1.5 HP
Type:	Electric Motor	Rated Voltage:	AC/DC 100V - 240V
Duty:	S1	Shaft Rotation:	CW/CCW
Part Number:	MPL-B430P-MJ72AA	Speed:	3450 RPM
Insulation Class:	F	Thickness:	2mm

Shaft Diameter:	5/8 Inch
Gross Weight:	220g
Interface:	PowerLink
Torque:	21g.cm
Frequency:	50HZ, 60HZ
Horsepower:	1.5 HP
Type:	Electric Motor
Rated Voltage:	AC/DC 100V - 240V
Duty:	S1
Shaft Rotation:	CW/CCW
Part Number:	MPL-B430P-MJ72AA
Speed:	3450 RPM
Insulation Class:	F
Thickness:	2mm

Description

Allen Bradley MPL-B430P-MJ72AA Low Inertia Servo Motor with High Output Brushless Design 5000 RPM 2.2 kW Output Power

Allen Bradley MPL-B430P-MJ72AA is an MP series low inertia servo motor. As part of the MP series, this motor features a high output brushless design and is specifically designed to reduce motor size while increasing output torque.

The rated speed of MPL-B430P-MJ72AA is 5000 RPM and the output power is 2.2 kW. Its rotor inertia is 0.00038 kilograms per square meter or 0.0033 pounds per inch- S2. It has a sustained stall torque of 6.55 Nm or 58 pound inches.; The peak stall torque is 19.8 Newton meters or 175 pound inches.; Continuous stall current of 9.2 amperes (0 peak) and peak stall current of 32.0 amperes (0 peak). This servo motor belongs to the 400 V class and is specially designed for a rated power supply voltage of 460VAC. This is a frame 4 motor with a magnet stack length of 76.2 millimeters or 3.0 inches. And equipped with a circular (SpeedTec) DIN connector, which can rotate 180 ° at right angles. For position feedback, the servo motor uses a multi turn high-resolution encoder and is equipped with a shaft key without a shaft seal. The shaft seal kit suitable for MPL-B430P-MJ72AA is MPL-SSN-A4B4. When installing the optional shaft seal, the motor reaches IP 66 rating, and dust prevention, strong water spraying, and room temperature water are prevented from entering the equipment. If there is no shaft seal, according to the direction of the motor, the motor's rating is IP53, IP 51, and IP 50.

The working temperature requirement for this servo motor is 0-40 ° C or 32-104 ° F, while the storage temperature is 30-70 ° C or -22-158 ° F. In addition, the motor must be stored in a non corrosive environment.

The working temperature range of MPL-B430P-MJ72AA servo motor is 32 to 104 degrees Fahrenheit or 0 to 40 degrees Celsius. The environmental rating of MPL-B430P-MJ72AA is IP66, with waterproof and dustproof functions, optional shaft key extension, relative humidity range of 5-95%, and no condensation. This powerful motor has a speed of 5000 revolutions per minute and is equipped with a SpeedTEC DIN connector that can rotate at a right angle of 180 degrees. This low inertia motor has a rated AC voltage of 460 volts and an output power of 2.2 kilowatts. The Allen Bradley MPL-B430P-MJ72AA low inertia motor can also operate under constant shaft load. The maximum rated radial load for the axial load force of the motor is 15 kilograms (42 pounds), and the zero radial load is 25 kilograms (55 pounds). The rated value of radial load force is 49 kilograms (109 pounds). The Allen Bradley servo motor provides continuous and peak stall torque capability. The peak stall torque of this high dynamic servo motor is 19.8 Nm (175 pounds per inch), and the continuous stall torque is 6.55 Nm (58 pounds per inch). The rated value of continuous stall current is 9.2 amperes (0 peak), and the rated value of peak stall current is 32 amperes (0 peak). Other specifications of the motor include a stack length of 30 (76.2 millimeters or 3.0 inches), a frame size of 4, and free mounting holes (F-type). It doesn't have brakes. In addition, Allen Bradley MPL-B430P-MJ72AA servo motors are commonly used in the Ultra3000, Kinetix 7000, Kinetix 2000, and Kinetix 6000 servo drive series.

Armature Voltage	460 V
Brake Option	No Brake
Connectors	SpeedTEC DIN Connector, Right Angle, 180° Rotatable (Quick Connect)
Magnet Stack Length	30 = 76.2 mm (3.0 in.)
Product Type	Servo Motor

Allen Bradley MPL-B430P-MJ72AA Low Inertia Servo Motor with High Output Brushless Design 5000 RPM 2.2 kW Output Power 0
