Introduction

The Single Motor Module 6SL3120-1TE22-4AD0 is a compact and high-performance drive designed for precise motor control in industrial automation systems. With a continuous output current of up to 24 A, it provides stable and efficient performance for applications requiring accurate speed and torque control.

Built for modular drive platforms, this unit integrates advanced power electronics, digital communication, and safety functions into a space-saving design. It is widely used in industries that demand reliability, consistency, and efficient operation.

Technical Specifications

• Product type: Single motor drive module
• Input voltage: 600 V DC (via DC link)
• Output voltage: 3-phase 400 V AC
• Rated output current: 24 A continuous
• Peak current: up to 48 A (short duration)
• Power range: approximately 11 kW
• Cooling method: internal fan cooling
• Mounting design: compact book-type structure
• Protection level: IP20 (front side)
• Communication: high-speed digital interface with network compatibility
• Safety features: integrated Safe Torque Off (STO)
• Compliance: meets major international industrial standards

Key Features

1. High-Precision Motor Control
Optimized switching technology improves efficiency and reduces motor noise, ensuring smooth and accurate operation. The module also supports short-term overload conditions, making it suitable for dynamic applications with varying load demands.

2. Modular Integration
The design allows easy integration into modular automation systems. Digital communication enables fast data exchange between components, simplifying system configuration and improving overall performance.

3. Compact and Durable Construction
The space-saving structure allows efficient use of control cabinet space. Internal cooling ensures stable operation even in enclosed environments, while robust construction supports long-term reliability.

4. Intelligent Diagnostics
Built-in monitoring functions track temperature and operating conditions in real time. This helps detect potential issues early and supports predictive maintenance, reducing downtime.

5. Energy Efficiency
High conversion efficiency helps lower energy consumption. Optimized power management reduces losses and supports cost-effective operation in continuous production environments.

Typical Applications

Textile Equipment
Provides stable control for spinning and weaving processes, ensuring consistent product quality.

Plastic Processing Machinery
Controls speed and torque in molding and extrusion systems for precise material handling.

Woodworking Machines
Supports accurate positioning and smooth motion in CNC cutting and finishing operations.

Packaging Systems
Enables coordinated motion control in automated packaging lines, improving speed and efficiency.

Installation and Setup

Mechanical Installation
The module can be mounted in control cabinets using standard mounting methods, allowing flexible placement and easy integration.

Electrical Connection

• Connect DC input to the power terminals
• Connect motor cables to output terminals
• Use shielded cables for communication and control signals

Commissioning
Automatic parameter detection and setup tools simplify configuration. The system can quickly identify connected components and optimize performance settings.

Advantages

Space Optimization
Compact design reduces cabinet size and allows higher system density.

Ease of Use
Simplified configuration and automatic setup reduce engineering time.

Reliable Operation
Integrated protection and monitoring features ensure stable performance under varying conditions.

Scalability
Compatible with modular systems, making it suitable for both new installations and upgrades.

Conclusion

The Single Motor Module 6SL3120-1TE22-4AD0 offers a balanced combination of precision, efficiency, and compact design. It is well suited for a wide range of industrial automation applications that require reliable motor control and consistent performance.

With its integrated features, intelligent monitoring, and energy-efficient operation, this module provides a practical solution for improving productivity and maintaining long-term system stability.
