The Single Motor Module 6SL3120-1TE23-0AA3 is a high-performance drive designed for precise and reliable motor control in industrial automation systems. With a continuous output current of up to 30 A, it delivers stable performance for applications that require dynamic response, accuracy, and efficiency.
Built for modular drive platforms, this unit integrates advanced power electronics, digital communication, and safety functions into a compact structure. It is well suited for industries that demand consistent quality, fast cycle times, and dependable operation.
Technical Specifications
- Product type: Single motor drive module
- Input voltage: 600 V DC (via DC link)
- Output voltage: 3-phase 400 V AC
- Rated output current: 30 A continuous
- Peak current: up to 60 A (short duration)
- Power range: approximately 15 kW
- Cooling method: internal fan cooling
- Mounting design: compact book-type structure
- Protection level: IP20 (front side)
- Communication: high-speed digital interface with network compatibility
- Safety features: integrated Safe Torque Off (STO)
- Compliance: meets major international industrial standards
Key Features
1. High-Dynamic Motor Control
Optimized switching technology improves efficiency and reduces motor noise, ensuring smooth and accurate operation. The module supports short-term overload conditions, making it suitable for applications with rapidly changing loads.
2. Modular Integration
The module is designed for easy integration into modular automation systems. Fast digital communication allows efficient data exchange between system components, improving coordination and performance.
3. Compact and Robust Design
Its space-saving structure allows efficient cabinet layout, while internal cooling ensures reliable operation even in enclosed environments. The durable construction supports long-term industrial use.
4. Intelligent Diagnostics
Built-in monitoring functions provide real-time tracking of temperature and operating status. This enables early fault detection and supports predictive maintenance, reducing unexpected downtime.
5. Energy Efficiency
High conversion efficiency helps reduce energy consumption. Optimized power management minimizes losses and supports cost-effective operation in continuous processes.
Typical Applications
Electronics Manufacturing
Supports high-precision motion control for assembly and handling systems requiring accurate positioning.
General Industrial Equipment
Provides stable and responsive control for machines with dynamic motion requirements.
Precision Metal Processing
Enables accurate speed and torque control in cutting, grinding, and finishing operations.
Food and Packaging Systems
Ensures consistent motion control for filling, sealing, and conveying processes, improving efficiency and reducing waste.
Installation and Configuration
Mechanical Installation
The module can be mounted in control cabinets using standard mounting methods, allowing flexible integration into existing systems.
Electrical Connection
- Connect DC input to the designated power terminals
- Connect motor cables to output terminals
- Use shielded cables for communication and control signals
Commissioning
Automatic setup tools help identify connected components and optimize parameters, reducing commissioning time and simplifying system configuration.
Advantages
Space Saving
Compact design reduces cabinet size and allows higher installation density.
Ease of Use
Quick setup and automatic configuration minimize engineering effort.
Reliable Performance
Integrated protection and monitoring functions ensure stable operation under varying conditions.
Scalable Design
Suitable for both new systems and upgrades within modular automation environments.
Conclusion
The Single Motor Module 6SL3120-1TE23-0AA3 offers a strong balance of precision, efficiency, and compact design. It is an effective solution for a wide range of industrial automation applications that require reliable and accurate motor control.
With integrated safety features, intelligent diagnostics, and energy-efficient performance, this module helps improve productivity while supporting long-term operational stability.
