Bosch Rexroth MHD112B-024-NP0-BN Synchronous Motor for Automation

Bosch Rexroth MHD112B-024-NP0-BN Synchronous Servo Motor

Order Number: R911277128

Overview

The Bosch Rexroth MHD112B-024-NP0-BN is a high-performance synchronous servo motor designed for precision motion control in industrial automation applications. As part of the MHD series, this motor combines advanced engineering, robust construction, and exceptional dynamic response, making it ideal for tasks requiring accuracy, reliability, and efficiency5. With its integrated feedback system and compatibility with Rexroth's digital drive controllers, the MHD112B-024-NP0-BN ensures seamless integration and optimized performance in complex automation environments. The "NP0" designation indicates specific features, such as a high-resolution encoder and enhanced thermal management, tailored for demanding operational conditions.

Key Features

1. High Precision and Resolution:
   The motor is equipped with a digital servo feedback (HSF) encoder, providing exceptional positional accuracy and repeatability. This makes it suitable for applications requiring tight tolerances, such as CNC machining and robotic assembly. The encoder supports real-time data transmission, reducing latency and improving overall system responsiveness.

2. Robust Design and Protection:
   With an IP65 protection rating, the motor is resistant to dust, water jets, and harsh industrial environments2. Its housing is coated with a black primer (RAL 9005) for corrosion resistance, and optional sealing air connections further enhance protection in settings involving coolants or oils. The motor's construction complies with international standards (e.g., DIN 42950), ensuring durability and longevity.

3. High Dynamic Performance:
   The motor delivers high torque density and low rotor inertia, enabling rapid acceleration and deceleration. It supports peak torque overload (up to 3x rated torque), making it ideal for applications with frequent start-stop cycles or sudden load changes, such as packaging machinery and automated production lines.

4. Thermal Management:
   Efficient cooling options include natural convection (standard) and forced air cooling (via an optional blower). For high-duty cycles, liquid cooling can be implemented to maintain optimal temperature levels and prevent overheating, ensuring consistent performance even under continuous operation.

5. Integration and Compatibility:
   The motor seamlessly integrates with Rexroth's IndraDrive series controllers7. Its encoder stores motor parameters (e.g., type code, control loop data), allowing for automatic configuration and reducing commissioning time. Support for industrial protocols like EtherCAT, PROFINET, and Ethernet/IP ensures interoperability with existing automation systems.

6. Safety and Compliance:
   The motor meets CE and UL standards (UL file number E163211) and can be equipped with an optional holding brake for safety-critical applications (e.g., vertical axes). Its design complies with international directives for machinery safety and EMC, ensuring safe operation in diverse industrial environments.

Technical Specifications

Design and Construction

• Frame and Mounting: The motor features a B05 flange design (per DIN 42950), supporting mounting positions IM B5, IM V1, and IM V3. The output shaft is balanced for smooth operation and can be configured as a plain shaft or with a featherkey (DIN 6885) for positive torque transmission.

• Encoder System: The digital encoder provides high-resolution feedback, ensuring accurate position and speed control. The encoder's data memory stores motor parameters, enabling plug-and-play integration with Rexroth drives.

• Connectors: Power and feedback connectors are designed for 270-degree rotation, allowing flexible cable routing. Optional angular connectors simplify installation in space-constrained applications.

Application Areas

The MHD112B-024-NP0-BN is ideal for high-precision industries:

1. Robotics: Provides precise motion control for articulated arms, grippers, and automated guided vehicles (AGVs).

2. Machine Tools: Ensures accuracy in CNC machining centers, lathes, and grinding machines1.

3. Packaging Machinery: Supports high-speed filling, labeling, and wrapping operations with synchronized motion1.

4. Automated Production Lines: Enables rapid positioning and synchronization in assembly and testing systems.

Integration and Maintenance

• Controller Compatibility: Works with Rexroth IndraDrive systems (e.g., HDC, HDS series) for optimized performance7. The drive auto-configures motor parameters via the encoder interface.

• Maintenance: Designed for 30,000 hours of operational life under rated conditions. Regular maintenance includes checking shaft seals, cleaning cooling fins, and verifying connector tightness.

• Cooling Options: For extreme loads, liquid cooling kits are available. The motor’s coolant connections use R1/8" threads for easy integration.

Ordering Information

The motor can be ordered with optional accessories:

• Holding Brake: Electrically released brake for safety positioning.

• Blower Unit: LEMD-series blower for enhanced surface cooling.

• Sealing Air Kit: Protects against invasive fluids in aggressive environments.

• Liquid Cooling: Components for high-duty cycle applications.

Why Choose the MHD112B-024-NP0-BN?

This motor stands out due to its:

• High Torque Density: Compact design delivering powerful performance.

• Ruggedness: IP65 protection and robust construction for harsh environments2.

• Energy Efficiency: Optimized electromagnetic design reduces power consumption.

• Global Support: Backed by Bosch Rexroth’s worldwide service network.

Conclusion

The Bosch Rexroth MHD112B-024-NP0-BN synchronous servo motor is a reliable, high-precision solution for advanced automation systems. Its combination of robust design, seamless integration, and exceptional dynamic performance makes it a top choice for industries seeking to enhance productivity and accuracy. For technical details or customization, refer to the official documentation or contact Rexroth’s support network.
