The B&R 8LVA23.B1030D200-0 is an 8LVA series synchronous servo motor designed for compact and dynamic motion control applications. The 8LVA motor series is suitable for machine designs where installation space is limited but reliable servo performance, accurate positioning, and high acceleration response are still required.

This model belongs to the 8LVA23 motor size and has 4 pole pairs. It is configured with a nominal speed of 3000rpm and a stall torque of 1.350Nm. The 8LVA23.B1030D200-0 version uses a smooth shaft, angled swivel connector, self-cooling design, IP54 protection rating, and no oil seal. It is supplied with a holding brake, and the brake holding torque is 2.20Nm.

The B1 encoder configuration uses an EnDat 2.2 inductive 16-line multi-turn encoder. This feedback design helps the control system identify motor position across multiple revolutions and supports reliable servo operation in motion control applications. Because 8LVA motors can have different encoder, shaft, brake, connector, and speed configurations, the complete model number should always be checked before ordering.

The 8LVA23.B1030D200-0 is commonly used in packaging machinery, feeder axes, conveyor systems, indexing machines, handling equipment, assembly automation, printing machinery, labeling equipment, compact production machines, and other industrial automation systems using B&R motion control architecture. It is especially suitable for compact servo axes that require high speed, small motor size, stable positioning performance, and axis holding support when the machine stops.

For replacement applications, please confirm the original motor nameplate, complete model number, servo drive model, encoder cable, motor power cable, brake wiring, shaft connection, connector angle, machine controller, and axis function. Clear photos of the motor label, shaft end, connector area, servo drive label, and installed machine position can help confirm compatibility and reduce replacement risk.

Dengfeng supplies B&R 8LVA synchronous motors, 8LS servo motors, 8MS motors, ACOPOS servo drives, ACOPOSmicro modules, X20 I/O modules, X67 modules, Power Panel units, industrial PCs, motor cables, encoder cables, and automation spare parts for machine repair and production line maintenance. Before shipment, we can check the model label, shaft condition, connector condition, brake condition, housing appearance, and packaging according to your request.

Key Features

• B&R 8LVA23.B1030D200-0 8LVA synchronous servo motor
• Compact 8LVA23 motor size
• 4 pole pairs
• 3000rpm nominal speed
• 6600rpm maximum speed
• 1.350Nm stall torque
• 1.300Nm rated torque
• 4.00Nm maximum torque
• B1 EnDat 2.2 inductive 16-line multi-turn encoder
• Smooth shaft design
• With holding brake
• 2.20Nm brake holding torque
• Without oil seal
• Angled swivel connector
• 50mm centering diameter with h7 fit
• Self-cooling design
• IP54 protection rating
• Suitable for compact servo axis control, replacement, repair, retrofit, and spare parts supply

Typical Applications

The B&R 8LVA23.B1030D200-0 synchronous servo motor can be used in:

• B&R motion control systems
• ACOPOS and ACOPOSmicro servo systems
• Packaging machinery
• Conveyor and feeder axes
• Rotary indexing systems
• Labeling machines
• Printing machinery
• Material handling systems
• Assembly automation
• Compact positioning axes
• Production line maintenance
• Servo motor replacement and repair projects

FAQ

Q1: What is B&R 8LVA23.B1030D200-0?
A1: B&R 8LVA23.B1030D200-0 is an 8LVA series synchronous servo motor used for compact industrial motion control and servo positioning applications.

Q2: What is the nominal speed of 8LVA23.B1030D200-0?
A2: The nominal speed is 3000rpm.

Q3: What is the stall torque of this motor?
A3: The stall torque is 1.350Nm.

Q4: Does 8LVA23.B1030D200-0 have a holding brake?
A4: Yes. This version is supplied with a holding brake, and the brake holding torque is 2.20Nm.

Q5: What shaft type does this model use?
A5: It uses a smooth shaft. Please check the coupling or mechanical connection before replacement.

Q6: What encoder does 8LVA23.B1030D200-0 use?
A6: It uses a B1 EnDat 2.2 inductive 16-line multi-turn encoder.

Q7: Does this motor have an oil seal?
A7: No. This version is without oil seal. Please check the operating environment if oil mist, coolant, or dust protection is required.

Q8: What connector type does this motor use?
A8: It uses an angled connector with swivel design.

Q9: What is the protection rating of this motor?
A9: The protection rating is IP54.

Q10: What is the difference between 8LVA23.B1030D200-0 and 8LVA23.B1030D000-0?
A10: 8LVA23.B1030D200-0 is the version with holding brake, while 8LVA23.B1030D000-0 is the related version without brake. The brake wiring and machine axis requirement must be checked before replacement.

Q11: Can 8LVA23.B1030D200-0 replace 8LVA33.B1021D200-0?
A11: Not directly without checking the machine configuration. 8LVA23.B1030D200-0 is a smaller 8LVA23 motor with 3000rpm and 1.350Nm stall torque, while 8LVA33.B1021D200-0 is a larger 8LVA33 motor with 2100rpm and 2.600Nm stall torque. Motor size, torque, speed, centering diameter, cable, drive setup, and machine parameters must match.

Q12: What should I check before ordering?
A12: Please check the original motor nameplate, complete model number, servo drive model, encoder cable, motor power cable, brake wiring, shaft connection, connector type, and machine axis function before ordering.

Q13: Can you help confirm compatibility?
A13: Yes. Please send photos of the original motor nameplate, shaft end, connector area, servo drive label, brake wiring, and installed axis position. We can help check whether 8LVA23.B1030D200-0 matches your replacement requirement.
