• The B&R 8LSA46.R2060D000-3 is an 8LS Series synchronous servo motor used in high-speed industrial motion control systems. It is designed for applications that require accurate positioning, stable speed response, compact motor installation, and dynamic torque output without a holding brake.

  This motor has 6000rpm nominal speed, 5Nm nominal torque, 3142W nominal power, 10Nm stall torque, and 38Nm maximum torque. With 400VAC motor class, 5 pole pairs, and self-cooling Type A construction, the 8LSA46.R2060D000-3 is suitable for high-speed servo axes in packaging machinery, printing machinery, textile equipment, material handling systems, indexing units, and automated production lines.

  The motor uses a 2-pole R2 resolver feedback system, smooth shaft d=19mm k6 × 40mm without oil seal, 95mm centering diameter with j6 fit, 100mm flange square dimension, and angled swivel connector. The angled connector design helps with cable routing in compact machine layouts and control cabinet installations.

  The key difference between 8LSA46.R2060D000-3 and 8LSA46.R2060D200-3 is the holding brake. The D000 version is supplied without holding brake and is normally used for horizontal axes, rotary axes, conveyor axes, or applications where shaft holding after power-off is not required. If the machine uses a vertical axis, lifting axis, or holding axis, the D200 brake version may be required.

  For replacement applications, the complete model number 8LSA46.R2060D000-3 must be confirmed carefully. Similar 8LSA46 motors may have the same speed and torque rating but different brake configuration, shaft type, encoder feedback, connector direction, or special option code. Before ordering, please confirm the original motor nameplate, servo drive model, brake requirement, motor cable, encoder cable, shaft type, flange size, centering diameter, and machine installation dimensions.

  Dengfeng supplies B&R 8LS servo motors, ACOPOS servo drives, ACOPOSmulti modules, ACOPOS P3 drives, motor cables, encoder cables, PLC modules, industrial PCs, power panels, and automation spare parts for machine repair and production line maintenance. Before shipment, we can check the model label, shaft condition, connector condition, encoder configuration, appearance, and packaging according to your request.

  Key Features

  B&R 8LSA46.R2060D000-3 synchronous servo motor 6000rpm nominal speed and 12000rpm maximum speed 5Nm nominal torque and 10Nm stall torque 38Nm maximum torque for dynamic servo axis operation 3142W nominal power and 6.1A nominal current 400VAC motor class with 5 pole pairs Self-cooling Type A construction 2-pole R2 resolver feedback Smooth shaft d=19mm k6 × 40mm without oil seal Angled swivel connector for flexible cable routing Without holding brake, 0Nm brake holding torque Suitable for high-speed servo axis replacement and machine maintenance

FAQ

Q1: What is B&R 8LSA46.R2060D000-3?
A1: It is an 8LS Series synchronous servo motor with 6000rpm nominal speed, 5Nm nominal torque, R2 resolver feedback, smooth shaft, angled swivel connector, and no holding brake.

Q2: What is the nominal speed of this motor?
A2: The nominal speed is 6000rpm, and the maximum speed is 12000rpm.

Q3: What torque does 8LSA46.R2060D000-3 provide?
A3: The nominal torque is 5Nm, the stall torque is 10Nm, and the maximum torque is 38Nm.

Q4: What is the nominal power of this motor?
A4: The nominal power is 3142W.

Q5: Does 8LSA46.R2060D000-3 include a holding brake?
A5: No. This D000 version is supplied without holding brake, and the brake holding torque is 0Nm.

Q6: What is the difference between 8LSA46.R2060D000-3 and 8LSA46.R2060D200-3?
A6: The D000 version is without holding brake, while the D200 version includes a holding brake. The brake version is normally used for vertical axes, holding axes, or lifting mechanisms.

Q7: What feedback does this motor use?
A7: It uses a 2-pole R2 resolver feedback system.

Q8: What shaft type does this model use?
A8: It uses a smooth shaft d=19mm k6 × 40mm without oil seal.

Q9: What connector direction does it use?
A9: It uses an angled swivel connector, which helps with cable routing in compact machine installations.

Q10: Can this motor be used as a replacement part?
A10: Yes. It can be used for replacement when the complete model number, brake configuration, encoder feedback, shaft type, connector direction, servo drive model, and mounting dimensions are compatible.

Q11: What should I check before ordering?
A11: Please confirm the original motor nameplate, brake requirement, servo drive model, motor cable, encoder cable, shaft type, flange size, centering diameter, and machine installation space.

Q12: Can you help confirm compatibility?
A12: Yes. Please send clear photos of the motor nameplate, servo drive label, cable connectors, and installation position before ordering.

• High-speed positioning systems
• Conveyor and transfer equipment
• Material handling systems
• Indexing mechanisms
• Automated production lines
• Rotary servo axis control
• Servo motor replacement and repair projects

Typical Applications

The B&R 8LSA46.R2060D000-3 servo motor can be used in:
