• The B&R 8LSA46.R2060D200-3 is an 8LS Series synchronous servo motor used in high-speed industrial motion control systems. It is designed for applications that require accurate positioning, stable speed response, dynamic torque output, and a holding brake for shaft position retention during stop or power-off conditions.

  This motor has 6000rpm nominal speed, 5Nm nominal torque, 10Nm stall torque, and 38Nm maximum torque. With 400VAC motor class, 5 pole pairs, and self-cooling Type A construction, the 8LSA46.R2060D200-3 is suitable for compact high-speed servo axes in packaging machinery, material handling systems, indexing units, printing machinery, and automated production lines.

  The motor uses R2 resolver feedback, a smooth shaft, 95mm centering diameter, 100mm flange square dimension, and angled swivel connector. The angled connector design helps with cable routing in machine frames and electrical cabinet layouts, while the resolver feedback supports reliable servo control in compatible drive systems.

  The key difference between 8LSA46.R2060D200-3 and the non-brake version 8LSA46.R2060D000-3 is the holding brake. The D200 version is selected for vertical axes, lifting axes, holding axes, indexing stations, or machine applications where the shaft position must be maintained after drive power is removed. If the original machine does not require a holding brake, the D000 version may be more suitable.

  For replacement applications, the complete model number 8LSA46.R2060D200-3 must be confirmed carefully. Similar 8LSA46 motors may have the same speed and torque rating but different brake configuration, shaft type, encoder feedback, connector direction, or special option code. Before ordering, please confirm the original motor nameplate, servo drive model, brake wiring, motor cable, encoder cable, mechanical mounting, and machine safety requirement.

  Dengfeng supplies B&R 8LS servo motors, ACOPOS servo drives, ACOPOSmulti modules, ACOPOS P3 drives, motor cables, encoder cables, PLC modules, industrial PCs, power panels, and automation spare parts for machine repair and production line maintenance. Before shipment, we can check the model label, shaft condition, connector condition, brake configuration, appearance, and packaging according to your request.

  Key Features

  B&R 8LSA46.R2060D200-3 synchronous servo motor 6000rpm nominal speed and 12000rpm maximum speed 5Nm nominal torque and 10Nm stall torque 38Nm maximum torque for dynamic servo axis operation 400VAC motor class with 5 pole pairs Self-cooling Type A construction R2 resolver feedback for servo control Smooth shaft configuration Angled swivel connector for flexible cable routing Integrated holding brake for vertical or holding axes 95mm centering diameter and 100mm flange square dimension Suitable for high-speed servo axis replacement and machine maintenance

FAQ

Q1: What is B&R 8LSA46.R2060D200-3?
A1: It is an 8LS Series synchronous servo motor with 6000rpm nominal speed, 5Nm nominal torque, R2 resolver feedback, smooth shaft, and holding brake.

Q2: Does 8LSA46.R2060D200-3 include a holding brake?
A2: Yes. This D200 version includes a holding brake for applications that require shaft position retention after stop or power-off.

Q3: What is the nominal speed of this motor?
A3: The nominal speed is 6000rpm, and the maximum speed is 12000rpm.

Q4: What torque does this motor provide?
A4: The nominal torque is 5Nm, the stall torque is 10Nm, and the maximum torque is 38Nm.

Q5: What feedback does this motor use?
A5: It uses a 2-pole R2 resolver feedback system.

Q6: What is the difference between 8LSA46.R2060D200-3 and 8LSA46.R2060D000-3?
A6: The D200 version has a holding brake, while the D000 version is supplied without holding brake. The brake version is usually selected for vertical axes, holding axes, or lifting mechanisms.

Q7: What shaft type does this model use?
A7: It uses a smooth shaft configuration. Please confirm the actual shaft dimensions with the original motor label and installation drawing before replacement.

Q8: What connector direction does it use?
A8: It uses an angled swivel connector, which helps with cable routing in compact machine installations.

Q9: Can this motor be used as a replacement part?
A9: Yes. It can be used for replacement when the complete model number, brake configuration, encoder feedback, shaft type, connector direction, servo drive model, and mounting dimensions are compatible.

Q10: What should I check before ordering?
A10: Please confirm the original motor nameplate, brake requirement, servo drive model, motor cable, encoder cable, shaft type, flange size, centering diameter, and machine installation space.

Q11: Can you help confirm compatibility?
A11: Yes. Please send clear photos of the motor nameplate, servo drive label, cable connectors, brake wiring, and installation position before ordering.

• Packaging machinery
• Indexing and positioning units
• Material handling systems
• Conveyor and transfer equipment
• Printing machinery
• Automated production lines
• High-speed servo axis systems
• Servo motor replacement and repair projects

Typical Applications

The B&R 8LSA46.R2060D200-3 servo motor can be used in:
