B&R ACOPOSmicro Inverter Module 80VD100PS.C00X-01: The Adaptive Power Core for Next-Generation Compact Automation

As industrial automation relentlessly advances toward higher density, energy intelligence, and flexible integration, the demands on power conversion systems intensify—particularly in space-constrained machinery where every millimeter and watt counts. The B&R ACOPOSmicro 80VD100PS.C00X-01 inverter module rises to this challenge, delivering a fusion of ultra-compact design, adaptive power management, and multi-domain control capabilities. Engineered as a dual-axis power core for low-to-mid power applications, this module transcends conventional servo drives by unifying stepper and servo control, dynamic voltage resilience, and embedded intelligence within a footprint under 50 cm² per axis. It represents B&R’s commitment to redefining motion control efficiency for tomorrow’s smart machines.

Architectural Innovations & Core Technologies

1. Adaptive Power Architecture

• Wide Voltage Operation: Supports 18–95 VDC input, enabling deployment in unstable grid environments while tolerating regenerative surges up to 95 VDC during braking.

• Hybrid Output Stage: Unified circuitry drives both two-phase stepper motors (10 A continuous/15 A peak) and servo motors (8 A continuous/15 A peak) without hardware reconfiguration.

• Integrated Energy Recovery: Unlike traditional drives wasting brake energy as heat, it channels regenerative power back to the DC bus, reducing external cooling demands by 40%.

2. Cyber-Physical Control System

• Embedded I/O & Safety: Features 4 high-speed digital inputs (5 μs response) and 2x 24 VDC outputs (0.5 A) for direct brake control or peripheral device management. Integrated Safe Torque Off (STO) meets SIL 3/PL e standards.

• Real-Time Communication: Leverages POWERLINK over Ethernet for deterministic axis synchronization (<400 μs cycle times), enabling multi-axis coordination without centralized controllers.

• Self-Monitoring Intelligence: Continuously tracks thermal load, current ripple, and insulation degradation, issuing predictive alerts via OPC UA or MQTT protocols.

3. Ultra-Compact Mechanical Design

• Space Optimization: At <50 cm² per axis, it achieves 60% higher power density than comparable drives, critical for multi-axis systems like robotic joints or PCB assembly arms.

• Modular Cooling: Supports conduction cooling (0.08°C/W) for sealed enclosures or forced air for high-temperature environments, eliminating external heatsinks.

Technical Specifications & Performance

*Table: Comprehensive Technical Profile of 80VD100PS.C00X-01*

Transformative Application Scenarios

1. High-Density Robotics

• Collaborative Robot Joints: Powers 6-axis cobots within arm cavities using conduction cooling, with STO ensuring human-robot safety. Voltage flexibility allows direct battery (24 VDC) or grid (48 VDC) operation.

• Mobile AGV Drivetrains: Regenerative braking recaptures 35% of kinetic energy during stops, extending battery life by 20%.

2. Precision Manufacturing

• Semiconductor Wire Bonders: Dual-axis synchronization maintains ±5 μm positioning accuracy while EMI-optimized switching prevents interference with nanoscale sensors.

• Pharmaceutical Dispensing: Adaptive microstepping (up to 256x) enables smooth fluid handling at 0.1 μl resolution, with embedded I/O triggering pumps/valves directly.

3. Sustainable Packaging

• Servo-Driven Fillers: Reduces energy consumption by 25% versus asynchronous motors, with POWERLINK synchronizing 20+ axes on one network.

• Flexible Format Changeovers: Software-switches between servo (high-speed) and stepper (high-torque) modes in <100 ms for rapid product resizing.

Competitive Differentiation

Ecosystem Integration & Engineering Efficiency

• Automation Studio Unified Environment: Configures motion logic, safety parameters, and I/O mapping in one platform. Simulates thermal/electrical loads before deployment.

• Multi-Protocol Connectivity: Native support for POWERLINK, CANopen, and EtherNet/IP enables seamless integration into Siemens, Rockwell, or B&R control architectures.

• Scalable Deployment: From single-axis conveyors to 50-axis printing presses—modules daisy-chain via DC bus sharing, eliminating redundant power supplies.

Conclusion: The Compact Power Nexus for Agile Automation

The ACOPOSmicro 80VD100PS.C00X-01 redefines compact automation by converging power delivery, motion intelligence, and safety into a singular, thumb-sized module. Its revolutionary voltage adaptability allows deployment from portable medical devices to heavy-duty AGVs, while dual-motor support slashes hardware diversity costs. For OEMs designing agile machinery in packaging, electronics, or logistics, this module delivers more than drive functionality—it provides an adaptive power ecosystem where energy efficiency, spatial constraints, and dynamic control coexist seamlessly.

In an era where flexibility dictates market survival, the C00X-01 transcends component-level thinking to become the strategic enabler of machine innovation—proving that the future of automation lies not in larger cabinets, but in smarter, denser, and profoundly more responsive power cores.
