The Graco Husky 1050 649034 is a high-capacity air operated double diaphragm pump designed for industrial fluid transfer, chemical processing, wastewater handling, and compatible coating applications. This configuration uses a polypropylene fluid section and polypropylene center section with PTFE balls, polypropylene seats, and two-piece PTFE/EPDM diaphragms.
The pump delivers a maximum flow rate of 189 L/min and can operate at pressures up to 8.6 bar. Its 1 in. female NPT fluid inlet and outlet support higher-volume transfer lines, while the 1/2 in. female NPT air inlet provides pneumatic power for stable operation.
The one-piece polypropylene center section helps reduce air-leak points, while the modular low-pulsation air valve supports smooth changeover and reliable continuous operation. The four-bolt construction provides even sealing pressure between pump components.
The 649034 is suitable for compatible acids, alkalis, detergents, process water, wastewater, slurry-containing liquids, and industrial fluids. Material compatibility must be verified before installation because the wetted components include polypropylene, PTFE, and EPDM.
Key Features
- Husky 1050 pneumatic diaphragm pump
- Maximum flow rate of 189 L/min
- Maximum fluid pressure of 8.6 bar
- Polypropylene fluid section and center section
- PTFE balls and polypropylene seats
- Two-piece PTFE/EPDM diaphragms
- 1 in. female NPT fluid inlet and outlet
- 1/2 in. female NPT air inlet
- 3/4 in. female NPT exhaust port
- Handles solids up to 3.2 mm
- Maximum operating temperature of 66°C
- Approximate pump weight of 8.2 kg
Applications
- Chemical transfer systems
- Industrial wastewater treatment
- Acid and alkali transfer
- Detergent and cleaning fluid handling
- Process water circulation
- Coating and ink transfer
- Bulk liquid dispensing
- General manufacturing fluid transfer
FAQ
Q1: What is the maximum flow rate of the 649034 pump?
A: The maximum free flow rate is 189 L/min, equivalent to 50 GPM.
Q2: What is the maximum working pressure?
A: The maximum fluid pressure and air pressure are both 8.6 bar, 0.86 MPa, or 125 psi.
Q3: What are the fluid connection sizes?
A: The fluid inlet and outlet are both 1 in. female NPT.
Q4: What materials are used in the pump?
A: The fluid section and center section are polypropylene. The seats are polypropylene, the balls are PTFE, and the diaphragms are two-piece PTFE/EPDM.
Q5: What is the maximum operating temperature?
A: The maximum operating temperature is 66°C.
Q6: Can this pump handle solids?
A: Yes. It can handle particles up to 3.2 mm, depending on fluid viscosity and operating conditions.
Q7: Is this pump suitable for every chemical?
A: No. Always verify chemical compatibility with polypropylene, PTFE, and EPDM before use.
