The B&R 8BVI0220HWS0.000-1 ACOPOSmulti Servo Drive Module is a high-current single-axis inverter module designed for demanding industrial motion applications requiring increased torque capability, precise positioning, and reliable servo performance.

Unlike ACOPOSmulti power supply modules, the 8BVI0220HWS0.000-1 does not generate the DC bus voltage. It receives power from the ACOPOSmulti DC bus and converts it into controlled motor output for one connected servo motor.

With a 22A current class and 16.2kW continuous power capability, this module is designed for larger servo motors, higher inertia loads, and applications requiring stronger acceleration and braking performance.

The single-axis architecture provides a dedicated servo channel, allowing independent configuration, commissioning, and optimization of each machine axis. Compared with compact ACOPOSmulti modules such as 8BVI0055HWS0.000-1 and 8BVI0110HWS0.000-1, the 8BVI0220HWS0.000-1 provides significantly higher output capability for more demanding mechanical systems.

Compared with the 8BVI0220HWD0.000-1 dual-axis version, this HWS model uses a single-axis design, making it suitable for machines where individual axis performance, flexible expansion, and independent servo tuning are required.

The integrated Safe Pulse Disabling (STO) function supports safety-oriented machine designs by preventing unintended motor torque generation during safety stop conditions. The module also provides motor brake connection and temperature sensor interfaces for complete servo motor integration.

The ACOPOSmulti modular architecture allows this inverter module to be combined with ACOPOSmulti power supply modules, mounting plates, controllers, and servo motors to create scalable industrial automation systems.

This product is a servo drive module only. It requires a compatible ACOPOSmulti power supply system and servo motor configuration.

Key Features

B&R ACOPOSmulti servo drive module

Single-axis inverter architecture

22A high-current servo output

16.2kW continuous power capability

750VDC DC bus operation

Dedicated servo axis control

Integrated Safe Pulse Disabling (STO)

Functional safety support

Motor brake connection

Motor temperature monitoring

Two ACOPOSmulti module slots

Wall-mounted modular design

Compatible with ACOPOSmulti servo motors

Typical Applications

High-speed packaging machinery

Industrial assembly equipment

Large positioning axes

Robotic motion systems

Printing and converting machines

Material handling equipment

High-load automation systems

Machine retrofit projects

Precision manufacturing equipment

Installation Notes

Before installation, verify:

Product model:

8BVI0220HWS0.000-1

Confirm:

ACOPOSmulti power supply capacity

DC bus voltage

Servo motor rated current

Encoder feedback type

Motor brake wiring

Temperature sensor connection

Safety circuit configuration

Required components:

• ACOPOSmulti Power Supply Module
• ACOPOSmulti Mounting Plate
• Motion Controller
• Compatible Servo Motor

Before commissioning:

Check DC bus voltage

Configure motor parameters

Verify encoder feedback

Test STO function

Check brake operation

Perform axis movement test

Confirm servo response

FAQ

Q

What is B&R 8BVI0220HWS0.000-1?

A

It is an ACOPOSmulti single-axis high-current servo drive module for industrial motion control systems.

Q

Is 8BVI0220HWS0.000-1 a power supply module?

A

No. It is a servo inverter module that receives DC bus power and controls one servo motor.

Q

How many axes can it control?

A

It controls one independent servo axis.

Q

What is the current rating?

A

The module belongs to the 22A high-current ACOPOSmulti servo drive class.

Q

What is the difference between 8BVI0220HWS0.000-1 and 8BVI0220HWD0.000-1?

A

The HWS version is a single-axis servo drive module, while the HWD version provides two-axis servo control.

Q

What is the difference between 8BVI0110HWS0.000-1 and 8BVI0220HWS0.000-1?

A

The 8BVI0220HWS0.000-1 provides a higher current class and power capability, making it suitable for larger motors and heavier mechanical loads.

Q

Does it support safety functions?

A

Yes. It supports Functional Safety and Safe Pulse Disabling (STO).

Q

Can it work independently?

A

No. It requires an ACOPOSmulti power supply, mounting system, controller, and compatible servo motor.
