The Graco 289771 is an AirPro HVLP air cap kit used as a repair and replacement part for compatible Graco AirPro HVLP air spray guns. It should be described as an air cap kit or spray gun repair part, not as a diaphragm pump, complete spray gun, spray nozzle, or pump assembly.

This air cap kit is designed for AirPro HVLP guns using 0.040-0.070 inch / 1.0-1.8mm nozzle sizes. The air cap plays an important role in spray atomization, spray pattern formation, coating transfer efficiency, and finishing quality. When the original air cap is worn, blocked, damaged, or contaminated, replacing it with the correct air cap kit can help restore stable spray performance.

The Graco 289771 air cap kit is commonly used in industrial finishing, automotive coating, metal parts spraying, furniture finishing, plastic parts coating, equipment repainting, maintenance workshops, and production line spray systems. It is suitable for repair teams and maintenance departments that need to keep AirPro HVLP spray guns working reliably.

For replacement applications, the complete part number 289771 must be checked carefully. Similar Graco AirPro air caps may look alike but can differ by spray technology, nozzle size range, spray pattern, gun type, and application material. Please do not replace an air cap only by appearance. The gun model, nozzle size, needle size, air cap number, and coating application should be confirmed before ordering.

Before ordering, please confirm the original spray gun model, old air cap part number, nozzle size, needle size, spray technology, material type, and required spray pattern. Clear photos of the gun label, old air cap marking, nozzle, needle, and spray gun front assembly can help confirm compatibility and reduce replacement risk.

Dengfeng supplies Graco spray gun repair parts, air cap kits, nozzles, needles, pump parts, diaphragm pump parts, coating system accessories, industrial automation parts, sensors, servo drives, motors, PLC modules, and maintenance spare parts for production line repair. Before shipment, we can check the part number, package condition, appearance, thread area, sealing area, and packing according to your request.

Key Features

• Graco 289771 AirPro HVLP air cap kit
• Repair part for compatible Graco AirPro HVLP air spray guns
• Suitable for 0.040-0.070 inch / 1.0-1.8mm nozzle size
• Used for air cap replacement and spray gun maintenance
• Helps support stable atomization and spray pattern quality
• Suitable for industrial finishing and coating applications
• Useful for paint spraying, metal finishing, furniture coating, plastic part coating, and workshop maintenance
• Not a diaphragm pump, complete spray gun, or general spray nozzle
• Suitable for repair, replacement, maintenance, and spare parts supply

Typical Applications

The Graco 289771 AirPro HVLP air cap kit can be used in:

• AirPro HVLP spray gun repair
• Industrial coating systems
• Automotive refinishing and coating
• Metal parts spraying
• Furniture finishing
• Plastic part coating
• Equipment repainting
• Paint shop maintenance
• Production line spray equipment
• Spray pattern troubleshooting
• Coating equipment spare parts replacement

FAQ

Q1: What is Graco 289771?
A1: Graco 289771 is an AirPro HVLP air cap kit used as a repair and replacement part for compatible Graco AirPro HVLP air spray guns.

Q2: Is Graco 289771 a diaphragm pump?
A2: No. It is not a diaphragm pump. It is an air cap kit for AirPro HVLP spray guns.

Q3: Is 289771 a complete spray gun?
A3: No. It is not a complete spray gun. It is a replacement air cap kit used on compatible AirPro HVLP spray guns.

Q4: What nozzle size is Graco 289771 suitable for?
A4: It is suitable for AirPro HVLP guns with 0.040-0.070 inch / 1.0-1.8mm nozzle sizes.

Q5: What spray technology does this air cap support?
A5: It is designed for HVLP spray gun applications.

Q6: What parts are included in the kit?
A6: The kit is commonly listed as an air cap kit and may include the air cap, washer, and O-ring depending on package configuration. Please confirm the actual package before ordering.

Q7: When should the air cap be replaced?
A7: It should be replaced when the original air cap is worn, damaged, blocked, contaminated, or causing poor spray pattern, uneven atomization, or unstable finishing quality.

Q8: Can Graco 289771 replace other AirPro air caps?
A8: It should only be used when the gun model, spray technology, nozzle size, needle size, and application requirement match. Similar-looking air caps may not be interchangeable.

Q9: What should I check before ordering?
A9: Please check the spray gun model, original air cap part number, nozzle size, needle size, spray technology, coating material, and required spray pattern before ordering.

Q10: Can you help confirm compatibility?
A10: Yes. Please send photos of the spray gun label, old air cap marking, nozzle, needle, and front gun assembly. We can help check whether Graco 289771 matches your replacement requirement.

Q11: What applications commonly use this part?
A11: It is commonly used in industrial finishing, automotive coating, metal parts spraying, furniture finishing, plastic part coating, equipment repainting, and paint shop maintenance.

Q12: Can this part improve spray performance?
A12: Replacing a worn or damaged air cap with the correct air cap kit can help restore spray pattern stability and atomization quality, but final spray performance also depends on gun setup, nozzle, needle, air pressure, coating material, and operator adjustment.
