TM5SMM6D2L Modicon TM5 Mixed I/O Module 4DI 2DO 1AI 1AO

The TM5SMM6D2L is a Modicon TM5 mixed I/O module combining digital and analog signal processing in one compact slice.

It provides four 24 V DC digital inputs, two protected transistor outputs, one analog input and one analog output.

The analog input accepts ±10 V, 0–20 mA or 4–20 mA signals. The analog output can be configured for ±10 V or 0–20 mA.

Its main advantage is mixed-signal flexibility. A small machine section can connect sensors, actuators, one process transmitter and one analog control device without installing four separate I/O modules.

Key Features

• Four digital inputs
• Two transistor outputs
• One analog input
• One analog output
• Voltage and current signal support
• 12-bit analog conversion
• Protected 0.5 A outputs
• Single compact TM5 slice

Typical Applications

• Small process skids
• Packaging stations
• Proportional valve control
• Pump and fan systems
• Standalone machine units

Four Digital Inputs

The module includes four 24 V DC sink inputs for:

• Proximity sensors
• Limit switches
• Push buttons
• Relay contacts
• Machine status signals

The digital inputs provide fast hardware filtering and configurable software filtering.

Two Digital Outputs

The module includes two 24 V DC source transistor outputs.

Maximum Current per Output

0.5 A

Maximum Total Current

1 A

The outputs include:

• Short-circuit protection
• Overload protection
• Thermal protection
• Automatic fault reset
• Reverse-polarity protection

One Analog Input

The analog input can be configured for:

• -10 to +10 V DC
• 0–20 mA
• 4–20 mA

Voltage Resolution

12-Bit Plus Sign

Current Resolution

12-Bit

The selected software range must match the physical transmitter wiring.

One Analog Output

The analog output supports:

• -10 to +10 V DC
• 0–20 mA

It can control compatible devices such as:

• Variable-speed drive references
• Proportional valves
• Analog positioners
• Process setpoints

The output does not provide a separate native 4–20 mA range. A controller program may restrict the command to the 4–20 mA portion when required.

TM5SMM6D2L vs Digital Mixed Module

TM5SMM6D2L

4 digital inputs

2 digital outputs

1 analog input

1 analog output

TM5SDM12DT

8 digital inputs

4 digital outputs

No analog channels

TM5SMM6D2L is selected when both analog and digital signals are required in one slice.

TM5SMM6D2L vs Separate I/O Modules

TM5SMM6D2L

Combines four signal types in one module.

Reduces the number of slices.

Suitable for small mixed-signal stations.

Separate Modules

Provide more channels of each signal type.

Offer greater expansion flexibility.

Better for larger centralized I/O groups.

Required Accessories

A complete installed slice normally includes:

• TM5SMM6D2L electronic module
• TM5ACBM11 or TM5ACBM15 bus base
• TM5ACTB12 terminal block
• Shielded cable for analog signals

FAQ

Q1: What is TM5SMM6D2L?

A1: It is a Modicon TM5 mixed I/O module with four digital inputs, two digital outputs, one analog input and one analog output.

Q2: What analog input signals are supported?

A2: The analog input supports ±10 V, 0–20 mA and 4–20 mA.

Q3: What analog output signals are supported?

A3: The analog output supports ±10 V and 0–20 mA.

Q4: What is the digital output current?

A4: Each output supports up to 0.5 A, with a maximum total of 1 A.

Q5: Does it have output protection?

A5: Yes. The digital outputs include short-circuit, overload and thermal protection.

Q6: What is the analog resolution?

A6: The analog channels use 12-bit resolution, with sign for bipolar voltage operation.

Q7: Is it a pure actuator output module?

A7: No. It combines digital inputs, digital outputs, analog input and analog output functions.

Q8: Which base and terminal block are required?

A8: It uses TM5ACBM11 or TM5ACBM15 with the TM5ACTB12 terminal block.
