The FANUC A06B-6079-H205 is an Alpha Series SVM2-20/40 dual-axis servo amplifier module designed for FANUC CNC machine tool systems.

This amplifier module provides control for two servo axes within a FANUC Alpha drive architecture. It receives DC bus power and controls compatible FANUC Alpha servo motors through digital servo communication and encoder feedback.

The SVM2-20/40 configuration supports two different servo output channels, with the L axis rated at 5.9 A and the M axis rated at 12.5 A. The module is suitable for CNC machining centers, milling machines, turning centers, and other industrial machine tools requiring reliable servo axis control.

The A06B-6079-H205 integrates protection functions including overcurrent, overvoltage, and thermal monitoring to improve system reliability during machine operation.

Before replacement, verify the CNC system model, servo motor type, encoder feedback wiring, axis assignment, jumper settings, and original amplifier configuration.

This product is a servo amplifier module only. It should not be described as a CNC controller, servo motor, spindle amplifier, power supply module, or standalone motion controller.

Key Features

FANUC Alpha SVM2-20/40 servo amplifier

Dual-axis servo control module

Supports two servo axes

283–325 VDC input voltage

3.9 kW rated input power

5.9 A L-axis output current

12.5 A M-axis output current

Digital servo control technology

Compatible with FANUC Alpha servo motors

Encoder feedback support

Overcurrent protection

Overvoltage protection

Thermal protection

CNC cabinet installation design

Typical Applications

CNC machining centers

CNC milling machines

CNC turning machines

Industrial machine tools

Precision manufacturing equipment

FANUC Alpha drive replacement projects

Machine repair and maintenance

Legacy CNC system upgrades

Installation Notes

Confirm the replacement model is A06B-6079-H205 before installation.

Check the following items before replacing the amplifier:

Servo motor model

CNC controller model

Axis assignment

Encoder feedback cable

DC bus voltage

Servo communication wiring

Jumper configuration

Machine parameters

The amplifier must be installed inside a suitable CNC electrical cabinet with proper grounding and ventilation.

After replacement, perform servo parameter verification, axis movement testing, and alarm checking before returning the machine to production.

FAQ

Q

What is A06B-6079-H205?

A

It is a FANUC Alpha SVM2-20/40 dual-axis servo amplifier module.

Q

How many axes can this amplifier control?

A

It can control two servo axes.

Q

What is the input voltage?

A

The rated input voltage is 283 to 325 VDC.

Q

What are the output current ratings?

A

The L axis is rated at 5.9 A and the M axis is rated at 12.5 A.

Q

Is A06B-6079-H205 a servo motor?

A

No. It is a servo amplifier module used to control FANUC Alpha servo motors.

Q

Can it work as a standalone servo drive?

A

No. It is designed to operate with compatible FANUC CNC systems.
