B&R 80VD100PD.C022-01 ACOPOSmicro Two Axis Servo Inverter Module Resolver
The B&R 80VD100PD.C022-01 is an ACOPOSmicro two-axis servo inverter module for compact motion systems that use resolver feedback.
This model can control two servo motors from one cabinet-mounted module. Its two resolver interfaces are the key configuration feature and make it suitable for machinery already designed around resolver-based motor feedback.
The module communicates through X2X POWERLINK and operates from a 24 to 64 VDC supply. It provides two motor connections with 8 A continuous current capability, making it suitable for compact handling axes, feeders, indexing mechanisms, and synchronized machine movements.
Two 24 VDC digital inputs can be used as trigger inputs. The module also includes one 24 VDC digital output, holding-brake connections, and an enable input for machine-side control functions.
This product is a servo inverter module only. It should not be described as a PLC, standard frequency inverter, servo motor, power supply module, encoder module, or standalone I/O module.
Key Features
Two-axis servo inverter module
X2X POWERLINK communication
Two resolver feedback interfaces
Two servo motor connections
24 to 64 VDC power supply range
8 A continuous current
Two trigger-capable digital inputs
One 24 VDC 1 A digital output
Motor holding-brake connection
Enable input
Optional braking resistor support
Compact ACOPOSmicro drive format
Typical Applications
Compact packaging machinery
Servo-driven feeders
Indexing mechanisms
Material handling units
Assembly equipment
Labeling machines
Pick-and-place systems
Two-axis resolver servo systems
Industrial motion retrofit projects
Installation Notes
Confirm that the original module is 80VD100PD.C022-01 and that the connected motors use resolver feedback.
Verify the X2X POWERLINK configuration, supply voltage, motor wiring, resolver wiring, brake wiring, enable circuit, and digital I/O assignment before commissioning.
Terminal blocks are ordered separately and should match the original machine installation.
Install the module in a properly grounded electrical control cabinet and retain the original shielding and cable-routing arrangement.
FAQ
Q
Is 80VD100PD.C022-01 a PLC controller
A
No it is a two-axis ACOPOSmicro servo inverter module
Q
How many servo motors can this module control
A
It supports two servo motor connections
Q
What feedback interface does this model use
A
It includes two resolver interfaces
Q
What communication interface does it use
A
It uses X2X POWERLINK communication
Q
What supply voltage is required
A
The module operates from 24 to 64 VDC with ±25 percent tolerance
