The B&R 80VD100PS.C08X-01 is an ACOPOSmicro inverter module designed for compact servo motor control in industrial automation systems. It is used for controlling one servo motor and is suitable for machines that require compact drive installation, stable servo axis control, and reliable positioning performance.

This module uses a POWERLINK interface and supports one SinCos encoder interface. It operates with a 24-64V DC ±25% power supply and provides one motor connection with 8A continuous current. The 80VD100PS.C08X-01 also includes two 24V DC sink digital inputs, which can be used as trigger inputs, and one 24V DC digital output rated at 1A. It provides a motor holding brake connection and enable input for machine axis control.

The ACOPOSmicro design is suitable for compact motion control systems where cabinet space and modular installation are important. This inverter module is commonly used in packaging machinery, feeder axes, conveyor systems, labeling equipment, printing machinery, small assembly machines, indexing mechanisms, material handling equipment, and other automated production systems using B&R motion control architecture.

For replacement applications, the complete model number 80VD100PS.C08X-01 must be checked carefully. Similar ACOPOSmicro inverter modules may look alike but can differ by interface type, encoder interface, motor connection quantity, output current, digital I/O configuration, terminal block type, firmware requirement, and machine configuration. Please do not replace this module only by appearance or by the 80VD100PS family name.

Before ordering, please confirm the old module label, POWERLINK system configuration, power supply voltage, servo motor model, encoder type, terminal block type, brake wiring, enable wiring, digital input wiring, digital output wiring, machine controller, and parameter backup. Terminal blocks and cables are ordered separately, so please check whether the existing accessories can be reused or whether new accessories are required.

Dengfeng supplies B&R ACOPOSmicro inverter modules, ACOPOS servo drives, ACOPOSmulti components, 8LVA motors, 8LS servo motors, X20 I/O modules, X67 modules, Power Panel units, industrial PCs, terminal blocks, cables, and automation spare parts for machine repair and production line maintenance. Before shipment, we can check the model label, housing condition, connector condition, terminal area, and packaging according to your request.

Key Features

• B&R 80VD100PS.C08X-01 ACOPOSmicro inverter module
• POWERLINK interface for motion control system integration
• Control for 1 servo motor
• 1x SinCos encoder interface
• 24-64V DC ±25% power supply
• 1 motor connection
• 8A continuous current
• 2 digital inputs, 24V DC, sink
• Digital inputs can be used as trigger inputs
• 1 digital output, 24V DC, 1A
• Motor holding brake connection
• Enable input
• Compact 65mm x 134mm x 95mm housing
• Screw mounting with heat spreader on mounting plate or cold plate
• Terminal blocks and cables must be ordered separately
• Suitable for replacement, repair, retrofit, and spare parts supply

Typical Applications

The B&R 80VD100PS.C08X-01 ACOPOSmicro inverter module can be used in:

• ACOPOSmicro motion control systems
• Compact servo motor control systems
• Packaging machinery
• Conveyor and feeder axes
• Labeling machines
• Printing machinery
• Small assembly machines
• Rotary indexing mechanisms
• Material handling systems
• Production line automation
• Servo drive replacement projects
• Machine retrofit projects
• Factory maintenance spare parts

FAQ

Q1: What is B&R 80VD100PS.C08X-01?
A1: B&R 80VD100PS.C08X-01 is an ACOPOSmicro inverter module used for compact servo motor control in industrial automation systems.

Q2: Is 80VD100PS.C08X-01 a stepper drive?
A2: No. It should be described as an ACOPOSmicro inverter module or servo inverter module. It is used for controlling one servo motor.

Q3: What interface does this module use?
A3: It uses a POWERLINK interface.

Q4: How many motors can 80VD100PS.C08X-01 control?
A4: It is designed for control of 1 servo motor and has 1 motor connection.

Q5: What encoder interface does this module have?
A5: It has 1x SinCos encoder interface.

Q6: What power supply does this module require?
A6: It requires a 24-64V DC ±25% power supply.

Q7: What is the continuous current rating?
A7: The continuous current rating is 8A.

Q8: Does this module have digital inputs and outputs?
A8: Yes. It has 2 digital inputs rated 24V DC sink, which can be used as trigger inputs, and 1 digital output rated 24V DC 1A.

Q9: Does 80VD100PS.C08X-01 support a motor holding brake?
A9: Yes. It includes a motor holding brake connection. Please check the motor brake wiring and terminal configuration before replacement.

Q10: Are terminal blocks included with 80VD100PS.C08X-01?
A10: The official product description states that terminal blocks must be ordered separately. The official product page also notes that terminal blocks and cables are ordered separately.

Q11: Can 80VD100PS.C08X-01 replace 80VD100PS.C00X-01?
A11: Not directly without checking the encoder interface. 80VD100PS.C08X-01 uses a SinCos encoder interface, while 80VD100PS.C00X-01 is listed with an EnDat 2.2 interface. The encoder type, motor, wiring, and machine configuration must match.

Q12: Can 80VD100PS.C08X-01 replace 80VD100PD.C088-01?
A12: Not directly without checking axis quantity and wiring. 80VD100PS.C08X-01 is a single-motor module, while 80VD100PD.C088-01 is listed as a dual-motor module with 2x SinCos encoder interfaces.

Q13: What should I check before ordering?
A13: Please check the original module label, POWERLINK configuration, motor model, encoder type, power supply voltage, terminal block type, brake wiring, enable wiring, and machine axis function before ordering.

Q14: Can you help confirm compatibility?
