The B&R 8V1640.00-2 is a high-power ACOPOS single-axis servo drive for industrial motion systems using a three-phase 400 to 480 VAC mains supply.
This model is rated for 64 A output current and 32 kW power. It is intended for machine axes that require higher drive capacity than compact servo modules, such as larger indexing systems, transfer mechanisms, converting equipment, lifting units, and high-inertia motion assemblies.
The drive includes an integrated line filter, braking resistor arrangement, DC bus power supply unit, and electronic safe restart interlock. Depending on the installed plug-in module, the hardware can be configured for communication or motor feedback functions such as POWERLINK, CAN, EnDat, resolver, SSI, HIPERFACE, or digital I/O.
The 8V1640.00-2 should be identified as a single-axis servo drive. It is not a PLC, power supply module, adaptive filter controller, vibration suppression controller, servo motor, or standalone fieldbus device.
Key Features
Single-axis ACOPOS servo drive
3 x 400 to 480 VAC mains supply
64 A rated output current
32 kW rated power
Integrated line filter
Integrated DC bus power supply unit
Integrated electronic safe restart interlock
Integrated or optional external braking resistor
Modular plug-in interface architecture
Optional POWERLINK V2 interface
Optional encoder and resolver interfaces
High-power cabinet-mounted drive format
Typical Applications
Large packaging machines
Rotary indexing systems
Servo-driven transfer units
Printing and converting equipment
Material handling systems
High-inertia motion axes
Industrial lifting mechanisms
Large assembly machines
Servo drive replacement projects
Installation Notes
Confirm the original part number, mains supply voltage, rated current, motor configuration, braking resistor arrangement, and installed plug-in modules before replacement.
The required feedback and communication functions depend on the fitted ACOPOS plug-in modules. Check the original interface modules before transferring hardware or commissioning a replacement drive.
Install the unit in a grounded control cabinet with the correct shielding and connector accessories. Verify motor cable routing, DC bus connections, braking resistor wiring, safety restart wiring, and machine parameters before startup.
The included shield component set and terminal block set should match the original hardware arrangement.
FAQ
Q
Is 8V1640.00-2 a servo motor
A
No it is a single-axis AC servo drive
Q
What is the rated power
A
The rated power is 32 kW
Q
What mains supply does it require
A
It is designed for three-phase 400 to 480 VAC supply
Q
Does it include a DC bus power supply unit
A
Yes it includes an integrated DC bus power supply unit
Q
Does it support POWERLINK
A
POWERLINK V2 support is available through the compatible optional plug-in module
Q
Is the encoder interface fixed on the main drive unit
A
No the encoder or feedback interface depends on the installed plug-in module
