The GYS101DC1-SB-B is a 100 W AC servo motor from Fuji Electric's FALDIC GYS Series, designed for compact motion systems requiring precise positioning and reliable load holding.
Its ultra-low inertia rotor structure provides fast acceleration and quick response for frequent start-stop operations. The integrated 16-bit absolute/incremental encoder delivers accurate feedback for servo positioning control.
The built-in electromagnetic holding brake is the key difference of this model, allowing the motor to maintain the mechanical position when servo power is removed.
This configuration is especially suitable for vertical axes, lifting mechanisms and applications where accidental movement after power interruption must be prevented.
Key Features
- 100 W compact servo motor
- Ultra-low inertia GYS design
- 16-bit ABS/INC encoder feedback
- Integrated holding brake
- 3000 r/min rated speed
- 5000 r/min maximum speed
- 200 V three-phase operation
- High-response positioning performance
Typical Applications
- Vertical lifting axes
- Small robots
- Pick-and-place systems
- Semiconductor equipment
- Precision positioning mechanisms
Ultra-Low Inertia Performance
The GYS series focuses on fast dynamic response rather than only torque output.
The low inertia rotor design provides:
- Faster acceleration
- Faster deceleration
- Shorter positioning cycles
- Improved repeatability
- Smooth high-frequency operation
This makes the motor suitable for compact automation equipment with frequent motion changes.
16-Bit ABS/INC Encoder Advantage
The integrated encoder combines absolute and incremental feedback functions.
Advantages include:
- High-resolution position detection
- Accurate speed feedback
- Reduced positioning error
- Improved servo tuning performance
Compared with standard incremental-only feedback, ABS/INC feedback can simplify machine restart procedures by retaining position information according to system configuration.
Integrated Holding Brake
The built-in brake is the main difference between GYS101DC1-SB-B and standard non-brake versions.
The brake helps:
- Hold vertical loads
- Prevent shaft movement during power-off
- Improve machine safety
- Maintain mechanical position
The brake is designed for holding and should not be used as a dynamic stopping brake.
GYS101DC1-SB-B vs GYS101DC1-SB
GYS101DC1-SB-B
100 W
16-bit ABS/INC encoder
With holding brake
GYS101DC1-SB
100 W
16-bit ABS/INC encoder
Without holding brake
The main difference is the integrated brake.
GYS101DC1-SB-B vs GYS101DC1-CB
GYS101DC1-SB-B
16-bit ABS/INC encoder
With brake
For vertical and holding applications
GYS101DC1-CB
16-bit incremental encoder
Without brake
Keyless shaft configuration
The encoder and brake configuration make them suitable for different machine requirements.
GYS101DC1-SB-B vs GYS101D5 Series
GYS101DC1-SB-B
FALDIC-Alpha generation
16-bit ABS/INC feedback
100 W with brake
GYS101D5 Series
ALPHA5 Smart generation
Higher-resolution encoder options
Updated servo-system compatibility
Selection should consider amplifier compatibility and feedback requirements.
Vertical Axis Application Advantage
For vertical mechanisms, servo power loss can create unwanted movement.
The integrated brake provides holding force when the motor is stopped or powered down.
Typical applications:
- Z-axis mechanisms
- Vertical feeders
- Lifting platforms
- Robot auxiliary axes
Installation Notes
Before installation:
- Confirm servo amplifier compatibility
- Verify encoder cable type
- Check brake wiring
- Confirm brake release timing
- Match load inertia
- Verify vertical-axis safety requirements
- Complete servo tuning
- Test brake operation
FAQ
Q1: What is the rated output of GYS101DC1-SB-B?
A1: The rated output is 100 W.
Q2: Does this motor include a brake?
A2: Yes. The SB-B version includes an electromagnetic holding brake.
Q3: What encoder does it use?
A3: It uses a 16-bit absolute/incremental encoder.
Q4: What is the rated speed?
A4: The rated speed is 3000 r/min.
Q5: What makes this model different from GYS101DC1-CB?
A5: It adds a holding brake and uses ABS/INC feedback instead of a standard incremental configuration.
Q6: Is it suitable for vertical applications?
A6: Yes. The integrated brake makes it suitable for axes requiring position holding.
Q7: Is the brake used for stopping motion?
A7: No. The brake is designed for holding position after stopping.
Q8: What type of machines use this motor?
A8: It is suitable for compact automation equipment requiring precision motion and reliable position retention.
