TM5SDO16T Modicon TM5 Digital Output Module 16DO 24V DC 0.5A

The TM5SDO16T is a Modicon TM5 digital output module with sixteen protected 24 V DC transistor outputs.

Each output can switch up to 0.5 A, while the combined current of all active channels must remain within the 8 A module limit.

Its main advantage is high output density. Sixteen low-current actuators can be controlled from one compact TM5 slice, reducing the number of output modules required in centralized machine stations.

The module includes short-circuit, overload and thermal protection, automatic fault reset and optional output monitoring.

Key Features

• Sixteen 24 V DC transistor outputs
• 0.5 A maximum per channel
• 8 A maximum total current
• Compact 1-wire output design
• 300-microsecond switching
• Short-circuit and overload protection
• Thermal protection
• Output fault monitoring

Typical Applications

• Indicator lamps
• Interface relays
• Small solenoid valves
• Pneumatic valve manifolds
• Packaging machinery

High-Density Output Control

TM5SDO16T is designed for machine sections with many low-current 24 V DC loads.

Typical uses include:

• Multiple relay coils
• Valve manifold channels
• Status indicators
• Conveyor control points
• Small pneumatic actuators

Current Limits

Maximum per Output

0.5 A

Maximum Total Module Current

8 A

All sixteen outputs may operate together only when the combined current remains within the approved total-current and temperature limits.

Protected Transistor Outputs

The module provides protection against:

• Short circuit
• Overload
• Excessive internal temperature
• Reverse polarity

After the fault is removed, the affected output can automatically reset.

Output Monitoring

Output monitoring can be enabled or disabled in software.

The monitoring function uses an approximate 10 ms delay and can report a detected output fault to the controller.

This helps identify overloaded, shorted or invalid output circuits.

TM5SDO16T vs TM5SDO4T

TM5SDO16T

Sixteen outputs

0.5 A per channel

8 A total

1-wire high-density connection

TM5SDO4T

Four outputs

0.5 A per channel

2 A total

1-wire, 2-wire or 3-wire connection

TM5SDO16T is suited to centralized output groups, while TM5SDO4T is better for smaller distributed load groups.

TM5SDO16T vs TM5SDO4TA

TM5SDO16T

More output channels

0.5 A per channel

Designed for multiple low-current loads

TM5SDO4TA

Four output channels

2 A per channel

Designed for fewer high-current actuators

Required Accessories

A complete installed slice normally requires:

• TM5SDO16T electronic module
• Compatible TM5 bus base
• Suitable terminal block
• 24 V DC I/O power segment

Confirm whether the base and terminal block are included before ordering.

FAQ

Q1: What is TM5SDO16T?

A1: It is a sixteen-channel Modicon TM5 transistor output module for 24 V DC loads.

Q2: What is the maximum current per output?

A2: Each channel can switch up to 0.5 A.

Q3: What is the total module current limit?

A3: The maximum combined output current is 8 A.

Q4: Does it have short-circuit protection?

A4: Yes. It includes short-circuit, overload and thermal protection.

Q5: Can it switch AC loads?

A5: No. It is intended for 24 V DC loads.

Q6: Is it a relay output module?

A6: No. It uses solid-state source transistor outputs.

Q7: What distinguishes it from TM5SDO4T?

A7: TM5SDO16T provides sixteen outputs and an 8 A total current capacity, while TM5SDO4T provides four outputs and a 2 A total limit.

Q8: What distinguishes it from TM5SDO4TA?

A8: TM5SDO16T offers higher channel density at 0.5 A per output, while TM5SDO4TA provides fewer channels with up to 2 A per output.
