B&R X20AI4632 4-Channel 16-Bit Fast Analog Input Module

Name: B&R X20AI4632 4-Channel 16-Bit Fast Analog Input Module
Brand: Dengfeng (Zhaoqing) Trading Co., Ltd
SKU: X20AI4632
Availability: InStock

Product Details

Place of Origin: Austria

Brand Name: B&R

Model Number: X20AI4632

Payment & Shipping Terms

Minimum Order Quantity: 1 piece

Packaging Details: Carton packaging

Delivery Time: 3-7 working days

Payment Terms: D/A, D/P, T/T, Western Union

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:

Product Family:	X20 System	Module Type:	High-resolution Analog Input Module
Number Of Inputs:	4	Supported Voltage Signal:	±10 V
Supported Current Signal:	0 To 20 MA	Input Type:	Differential
Converter Resolution:	16-bit Including Sign	Conversion Time:	50 µs For All Inputs
Voltage Input Impedance:	20 MΩ	Current Input Load:	Less Than 400 Ω
Conversion Method:	SAR	Input Filter:	Third-order Low-pass, 10 KHz Cutoff
Oscilloscope Function:	Supported	Electrical Isolation:	Channels Isolated From Bus
Power Consumption:	0.01 W Bus; 1.5 W Internal I/O	Required Terminal Block:	X20TB12, Ordered Separately
Compatible Bus Module:	X20BM11 Or X20BM15, Ordered Separately	Operating Temperature:	-25 To 60°C Horizontal; -25 To 50°C Vertical
Protection Rating:	IP20

Product Family:	X20 System
Module Type:	High-resolution Analog Input Module
Number Of Inputs:	4
Supported Voltage Signal:	±10 V
Supported Current Signal:	0 To 20 MA
Input Type:	Differential
Converter Resolution:	16-bit Including Sign
Conversion Time:	50 µs For All Inputs
Voltage Input Impedance:	20 MΩ
Current Input Load:	Less Than 400 Ω
Conversion Method:	SAR
Input Filter:	Third-order Low-pass, 10 KHz Cutoff
Oscilloscope Function:	Supported
Electrical Isolation:	Channels Isolated From Bus
Power Consumption:	0.01 W Bus; 1.5 W Internal I/O
Required Terminal Block:	X20TB12, Ordered Separately
Compatible Bus Module:	X20BM11 Or X20BM15, Ordered Separately
Operating Temperature:	-25 To 60°C Horizontal; -25 To 50°C Vertical
Protection Rating:	IP20

Description

B&R X20AI4632 4-Channel 16-Bit Fast Analog Input Module

The B&R X20AI4632 is intended for analog signals that require faster acquisition and finer digital resolution. It converts all four differential inputs within 50 µs and supports ±10 V or 0 to 20 mA signals.

Compared with X20AI4622, the X20AI4632 increases converter resolution from 13-bit to 16-bit and reduces conversion time from 400 to 50 µs. Its 10 kHz input filter and oscilloscope functions make it more suitable for rapidly changing machine signals.

Key Features

Four differential analog inputs
16-bit converter resolution
50 µs conversion for all channels
±10 V or 0 to 20 mA input
10 kHz hardware input filter
Oscilloscope acquisition functions

Typical Applications

Fast pressure monitoring
Dynamic tension measurement
Position and speed feedback
Test and measurement systems
High-speed process acquisition

FAQ

Q: Does X20AI4632 provide a dedicated 4 to 20 mA range?

A: Its specified current range is 0 to 20 mA. For a native configurable 4 to 20 mA range, X20AI4622 is the closer alternative.

Q: Why select X20AI4632 instead of X20AI4622?

A: Select X20AI4632 when higher resolution, a 50 µs conversion time or oscilloscope functions are required.

Q: Are the four channels isolated from each other?

A: No. The channels are isolated from the bus but not from one another.
