B&R X20DI9371 12-Channel 24VDC Sink Digital Input Module

Name: B&R X20DI9371 12-Channel 24VDC Sink Digital Input Module
Brand: Dengfeng (Zhaoqing) Trading Co., Ltd
SKU: X20DI9371
Availability: InStock

Product Details

Place of Origin: Austria

Brand Name: B&R

Model Number: X20DI9371

Payment & Shipping Terms

Minimum Order Quantity: 1 piece

Packaging Details: Carton packaging

Delivery Time: 3-7 working days

Payment Terms: D/A, D/P, T/T, Western Union

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:

Product Family:	X20 System	Module Type:	Digital Input Module
Number Of Inputs:	12	Nominal Input Voltage:	24 VDC
Input Circuit:	Sink	Connection Type:	1-wire Connections
Input Characteristics:	EN 61131-2 Type 1	Input Current:	Typically 3.75 MA At 24 VDC
Hardware Input Filter:	Maximum 100 µs	Software Input Filter:	0 To 25 Ms, Configurable In 0.2 Ms Increments
Switching Threshold:	Low Below 5 VDC; High Above 15 VDC	Electrical Isolation:	Channels Isolated From Bus
Power Consumption:	0.18 W Bus; 1.75 W Internal I/O	Required Terminal Block:	X20TB12, Ordered Separately
Compatible Bus Module:	X20BM11 Or X20BM15, Ordered Separately	Operating Temperature:	-25 To 60°C Horizontal; -25 To 50°C Vertical
Protection Rating:	IP20

Product Family:	X20 System
Module Type:	Digital Input Module
Number Of Inputs:	12
Nominal Input Voltage:	24 VDC
Input Circuit:	Sink
Connection Type:	1-wire Connections
Input Characteristics:	EN 61131-2 Type 1
Input Current:	Typically 3.75 MA At 24 VDC
Hardware Input Filter:	Maximum 100 µs
Software Input Filter:	0 To 25 Ms, Configurable In 0.2 Ms Increments
Switching Threshold:	Low Below 5 VDC; High Above 15 VDC
Electrical Isolation:	Channels Isolated From Bus
Power Consumption:	0.18 W Bus; 1.75 W Internal I/O
Required Terminal Block:	X20TB12, Ordered Separately
Compatible Bus Module:	X20BM11 Or X20BM15, Ordered Separately
Operating Temperature:	-25 To 60°C Horizontal; -25 To 50°C Vertical
Protection Rating:	IP20

Description

B&R X20DI9371 12-Channel 24VDC Sink Digital Input Module

The B&R X20DI9371 is a high-density digital input module providing twelve 24 VDC sink inputs within a 12.5 mm X20 slice. Its 1-wire connection layout is intended for control cabinets where channel density and compact wiring are more important than individual sensor supply terminals.

Unlike the source-wired X20DI9372, the X20DI9371 uses a sink input circuit. It also differs from the X20DI2377, which has only two inputs but adds dedicated 50 kHz event-counter and gate-measurement functions.

Key Features

Twelve 24 VDC digital inputs
Sink input wiring
Space-saving 1-wire connections
Configurable software filter for all channels
Channel-to-bus electrical isolation
Compact 12.5 mm X20 module width

Typical Applications

Packaging machine sensors
Conveyor status monitoring
Assembly line limit switches
Machine interlock inputs
High-density control cabinets

FAQ

Q: What is the difference between X20DI9371 and X20DI9372?

A: Both provide twelve 24 VDC inputs, but X20DI9371 is designed for sink input wiring while X20DI9372 is designed for source input wiring.

Q: Can X20DI9371 be used as a dedicated high-speed counter?

A: It is intended for standard digital input acquisition. For two dedicated 50 kHz event counters, X20DI2377 is the more appropriate module.

Q: Are the terminal block and bus module included?

A: No. A compatible X20TB12 terminal block and X20BM11 or X20BM15 bus module must be selected separately.
