The Danfoss 131B0041 is a VLT AutomationDrive FC-302 frequency converter with the full model number FC-302P5K5T5E20H1XGXXXXSXXXXAXBXCXXXXDX. It is designed for industrial motor speed control applications that require reliable operation, flexible motor control, and stable performance in automated production equipment.

This FC-302 model is rated at 5.5kW / 7.5HP and supports three phase 380-500V AC mains input. It uses an IP20 / chassis enclosure and an RFI Class A1/B (C1) filter. The unit is supplied without a brake chopper, with a graphical local control panel, standard cable entries, not coated PCB, no mains option, and A3 frame size. This configuration is suitable for control cabinet installation and machine drive replacement projects.

The VLT AutomationDrive FC-302 series is widely used for demanding automation applications where motor speed, torque response, and process control stability are important. It can be used in conveyors, mixers, pumps, fans, extruders, packaging machinery, textile equipment, material handling systems, production line equipment, and general industrial machine control.

For replacement applications, the complete model code must be checked carefully. FC-302 drives can look similar from the outside, but they may differ by power rating, voltage class, enclosure, RFI filter, brake chopper option, local control panel, PCB coating, fieldbus option, I/O option, software option, frame size, and terminal configuration. The full model FC-302P5K5T5E20H1XGXXXXSXXXXAXBXCXXXXDX and order code 131B0041 should be confirmed before ordering.

This model has no A option and no B option, so it should not be described as a PROFIBUS DP version unless the actual installed unit has an additional option card fitted and verified by photo. For accurate replacement, please check the drive nameplate, option card label, control terminal wiring, motor power, mains voltage, machine function, and parameter backup requirement before ordering.

Dengfeng supplies Danfoss VLT AutomationDrive FC-302 frequency converters, FC-301 drives, FC-102 drives, soft starters, control panels, option cards, power modules, industrial control boards, PLC modules, servo drives, motors, sensors, cables, and automation spare parts for machine repair and production line maintenance. Before shipment, we can check the model label, housing condition, terminal condition, keypad condition, fan condition, and packaging according to your request.

Key Features

• Danfoss 131B0041 VLT AutomationDrive FC-302 frequency converter
• Full model number FC-302P5K5T5E20H1XGXXXXSXXXXAXBXCXXXXDX
• 5.5kW / 7.5HP power rating
• Three phase 380-500V AC mains input
• IP20 / chassis enclosure
• RFI Class A1/B (C1) filter
• Graphical local control panel
• No brake chopper
• Not coated PCB
• Standard cable entries
• A3 frame size
• No A option, no B option, no C1 option, no D option
• Suitable for motor speed control, machine repair, retrofit, and spare parts supply

Typical Applications

The Danfoss 131B0041 FC-302 frequency converter can be used in:

• Industrial motor speed control systems
• Packaging machinery
• Conveyor systems
• Material handling equipment
• Pumps and fans
• Mixers and agitators
• Textile machinery
• Extruder equipment
• Production line automation
• Machine retrofit projects
• Control cabinet replacement
• Factory maintenance spare parts

FAQ

Q1: What is Danfoss 131B0041?
A1: Danfoss 131B0041 is a VLT AutomationDrive FC-302 frequency converter with the full model number FC-302P5K5T5E20H1XGXXXXSXXXXAXBXCXXXXDX.

Q2: What is the power rating of FC-302P5K5T5E20H1XGXXXXSXXXXAXBXCXXXXDX?
A2: This model is rated at 5.5kW / 7.5HP.

Q3: What input voltage does this FC-302 drive support?
A3: It supports three phase 380-500V AC mains input.

Q4: What enclosure type does this model use?
A4: It uses an IP20 / chassis enclosure, suitable for control cabinet installation.

Q5: Does this model include a brake chopper?
A5: No. This configuration is supplied without a brake chopper. Please check the braking requirement before using it in high-inertia or frequent braking applications.

Q6: Does this drive include a graphical local control panel?
A6: Yes. This model includes a graphical local control panel.

Q7: Does FC-302P5K5T5E20H1XGXXXXSXXXXAXBXCXXXXDX include PROFIBUS DP?
A7: No. According to the model code, this configuration has no A option and no B option. It should not be described as a PROFIBUS DP version unless an option card is physically installed and confirmed.

Q8: What RFI filter does this model have?
A8: It has an RFI Class A1/B (C1) filter.

Q9: What frame size is this FC-302 model?
A9: The frame size is A3.

Q10: Can this drive replace another FC-302 model?
A10: It can replace the same model when the power rating, voltage class, enclosure, brake option, filter, option cards, software, frame size, and machine parameter settings match.

Q11: What should I check before ordering?
A11: Please check the drive nameplate, order code, full model number, motor power, mains voltage, option card labels, wiring terminals, parameter backup, and machine application before ordering.

Q12: Can you help confirm compatibility?
A12: Yes. Please send photos of the old drive nameplate, option card label, control terminals, power terminals, keypad display, and machine cabinet layout. We can help check whether Danfoss 131B0041 matches your replacement requirement.
