The FANUC A06B-6089-H101 is an Alpha Series SVU1-12 servo amplifier unit used for FANUC CNC servo axis control. It is a single-axis servo amplifier designed for 200V class CNC machine systems and is commonly used in machine tools that require stable servo motor control, accurate positioning, and reliable axis operation.

This model is identified as SVU1-12 in the FANUC Alpha Series servo amplifier family. The SVU1-12 configuration means a one-axis servo unit with a 12A class rating. The A06B-6089-H101 is used in original FANUC CNC machine configurations and should be replaced according to the full part number, machine wiring, servo motor combination, control interface, and parameter settings.

This product should be described as a FANUC servo amplifier unit or servo drive amplifier, not as a Rockwell Kinetix drive, not as 2198-D032-ERS3, and not as a general inverter. If the page image and actual stock are A06B-6089-H101, the product title, parameter table, product description, FAQ, SEO title, and SEO keywords should all be changed to FANUC A06B-6089-H101 to avoid model conflict.

The A06B-6089-H101 is commonly used in CNC machining centers, turning centers, milling machines, grinding machines, drilling machines, mold machining equipment, and other FANUC CNC production machines. It can be used when an existing SVU1-12 servo amplifier reports alarms, fails to enable, has axis drive faults, or needs to be replaced during maintenance.

For replacement applications, the complete machine configuration must be checked carefully. Please confirm the old amplifier nameplate, CNC control system, servo motor model, axis assignment, power supply module, wiring board, PCB version, jumper setting, DIP switch setting, feedback cable, power cable, alarm code, and parameter backup before ordering. The same part number is usually the safest replacement route, but the original machine configuration should still be verified before installation.

Dengfeng supplies FANUC Alpha Series servo amplifier units, SVU servo amplifiers, SVM servo amplifier modules, spindle amplifier modules, power supply modules, CNC control units, servo motors, encoder cables, power cables, control boards, I/O modules, operator panels, and automation spare parts for CNC machine repair and production line maintenance. Before shipment, we can check the model label, housing condition, connector condition, fan condition, terminal condition, board condition, and packaging according to your request.

Key Features

• FANUC A06B-6089-H101 Alpha Series servo amplifier unit
• SVU1-12 / SVU 1-12 model configuration
• Single-axis / 1-axis servo amplifier
• 12A class servo unit
• 200V class CNC servo amplifier
• Used for FANUC CNC servo axis control
• Wiring board A16B-2202-0950
• PCB specification A20B-2002-0030
• Suitable for original machine configuration replacement
• Used in machining centers, turning centers, milling machines, and production equipment
• Useful for CNC machine repair, retrofit, spare parts supply, and factory maintenance

Typical Applications

The FANUC A06B-6089-H101 SVU1-12 servo amplifier can be used in:

• FANUC CNC servo systems
• CNC machining centers
• CNC turning centers
• CNC milling machines
• Grinding machines
• Drilling machines
• Mold machining equipment
• Precision metalworking machines
• Automated production machinery
• Single-axis servo control systems
• CNC machine retrofit projects
• Factory maintenance spare parts
• Servo amplifier replacement projects

FAQ

Q1: What is FANUC A06B-6089-H101?
A1: FANUC A06B-6089-H101 is an Alpha Series SVU1-12 servo amplifier unit used for FANUC CNC servo axis control.

Q2: Is A06B-6089-H101 a single-axis servo amplifier?
A2: Yes. It is a single-axis / 1-axis servo amplifier unit.

Q3: What is the model name of A06B-6089-H101?
A3: The model name is SVU1-12, also written as SVU 1-12.

Q4: What voltage class is this amplifier?
A4: It is a 200V class FANUC CNC servo amplifier. Some listings describe it as suitable for 200-230V AC machine systems, depending on the original configuration.

Q5: What does SVU1-12 mean?
A5: SVU1-12 identifies a one-axis FANUC Alpha Series servo unit with a 12A class rating.

Q6: Is this product Rockwell 2198-D032-ERS3?
A6: No. If the actual displayed product is FANUC A06B-6089-H101, it should not be described as Rockwell 2198-D032-ERS3. The page content should be corrected to FANUC A06B-6089-H101 to avoid model conflict.

Q7: Is A06B-6089-H101 a spindle amplifier?
A7: No. It is a servo amplifier unit, not a spindle amplifier, CNC controller, PLC module, or general inverter.

Q8: Can A06B-6089-H101 replace A06B-6089-H102?
A8: It should not be replaced only by appearance. A06B-6089-H101 is SVU1-12, while A06B-6089-H102 is commonly listed as SVU1-20. Current rating, servo motor, CNC parameters, wiring, and machine configuration must be checked.

Q9: What should I check before ordering this amplifier?
A9: Please check the old amplifier nameplate, full model number, CNC system, servo motor model, axis assignment, wiring board, PCB version, jumper setting, DIP switch setting, alarm code, and parameter backup before ordering.

Q10: Why is the original machine configuration important?
A10: FANUC servo amplifier replacement depends on the connected CNC control, servo motor, wiring, board version, switch settings, and parameters. Matching only the outside appearance may cause alarms or axis operation problems.

Q11: What applications commonly use this module?
A11: It is commonly used in FANUC CNC machining centers, turning centers, milling machines, grinding machines, drilling machines, mold machining equipment, and automated production equipment.

Q12: Can you help confirm compatibility?
A12: Yes. Please send photos of the original amplifier label, wiring board, PCB label, jumper and DIP switch settings, cabinet wiring, connected servo motor label, CNC system label, and alarm display. We can help check whether A06B-6089-H101 matches your replacement requirement.
