HCS02.1E-W0012-A-03-NNNN 11.5A 1.5kW Converter Power Section

The HCS02.1E-W0012-A-03-NNNN is the smallest HCS02 current class selected for this batch. It provides 11.5 A maximum current and 4.5 A continuous-current reference in a compact power section commonly applied to approximately 1.5 kW single-axis duties.

R911298371 identifies the power section, not the complete drive configuration. The installed CSB or CSH control section supplies the communication, encoder and safety interfaces. This distinction is essential for accurate product titles and quotations, because an eBay listing may show the same HCS02 model with different control sections attached.

Key Features

· 11.5 A maximum and 4.5 A continuous current

· Typical 1.5 kW motor class

· Compact 65 mm nominal width

· 3 AC 200 to 500 V mains class

· Control-section slot for configurable interfaces

· IP20 internal-air-cooled construction

Typical Applications

· Small pick-and-place axes

· Indexing tables

· Light conveyor systems

· Spare power section for existing HCS02 W0012 assemblies

Compatibility and Selection Note

Confirm R911298371 and document the installed control section separately. A listing that includes a CSB or CSH unit must state its complete order code rather than transferring its interface features to the HCS02 power-section code.

Frequently Asked Questions

Q1 Is W0012 a 12 A continuous rating?

No. The model class corresponds to approximately 11.5 A maximum current. The reference continuous current is 4.5 A.

Q2 Does the HCS02 power section contain the fieldbus?

The fieldbus is provided by the installed control section. It cannot be determined from HCS02.1E-W0012-A-03-NNNN alone.

Q3 Can a W0028 power section replace W0012?

A higher current class is not automatically a compatible replacement. Check cabinet dimensions, mains components, control section support, parameters and motor data.

Q4 What does IP20 require?

The unit must be mounted in a suitable cabinet that protects it from moisture, contamination and accidental access.

Q5 Is firmware included with R911298371?

Firmware belongs to the control-section configuration and must be identified separately.

Q6 Which codes should appear on the quote?

List R911298371, the full HCS02 code, the full CSB or CSH code and the firmware code when a complete assembly is offered.
