HCS02.1E-W0028-A-03-NNNN 28.3A 4kW Converter Power Section

The HCS02.1E-W0028-A-03-NNNN is a single-axis converter power section that changes a 200 to 500 V three-phase mains supply into controlled three-phase output for a servo motor. Its 28.3 A maximum-current class and 12 A continuous-current reference suit approximately 4 kW motion axes in packaging, printing, handling and general production equipment. This HCS02 unit provides the power stage and requires a separate CSB or CSH control section for motion control, communication, encoder processing and safety functions. The installed control section and firmware therefore determine how the completed drive operates within the machine system.

Key Features

• 28.3 A maximum and 12 A continuous-current reference
• Typical 4 kW motor-power class
• 3 AC 200 to 500 V direct mains connection
• 2.5-times overload capability subject to planning limits
• Control-section slot for application-specific interfaces
• IP20 cabinet design with internal air cooling

Typical Applications

• Medium-power packaging axes
• Handling and assembly equipment
• Machine-tool auxiliary axes
• Mid-power single-axis motion systems

Supply and Inquiry Information

Supply is confirmed against HCS02.1E-W0028-A-03-NNNN and material number R911298374. For an availability check and quotation, provide quantity, destination country, requested condition, delivery target, nameplate photo and the code of the required or existing CSB or CSH control section. The quote must state whether it covers only the HCS02 power section or a tested assembly with control section, firmware, connectors and accessories.

FAQ

Q1 Can I request the exact HCS02.1E-W0028-A-03-NNNN for purchase?

Yes. Use the complete model and material number R911298374 in the inquiry. Current availability, condition and lead time are confirmed for the requested quantity.

Q2 What information is required for a formal quotation?

Provide HCS02.1E-W0028-A-03-NNNN, R911298374, quantity, destination country, requested condition, required delivery date and clear nameplate photos. Include the installed firmware and related system codes when available.

Q3 What is included in the quoted scope?

The quotation should list the bare power section or complete assembly with CSB or CSH control section separately. Items not stated in the offer should not be assumed to be included.

Q4 Can a similar HCS model replace this exact unit?

Do not replace W0028 with W0012, W0054 or W0070 based on enclosure appearance. Match the 28.3 A class, 12 A continuous reference, dimensions, mains arrangement, control section and material number R911298374.

Q5 How are price and lead time determined?

Price and lead time are confirmed after the 28.3 A HCS02 power section, requested condition, quantity, delivery destination and test scope have been matched to current supply.

Q6 What must be verified before installing the replacement power section?

Compare the complete order code and R911298374, current and mains classes, dimensions, cooling, choke arrangement, motor load, CSB or CSH control section and firmware project.
