HCS02.1E-W0054-A-03-NNNN 54A 7.5kW Converter Power Section

The HCS02.1E-W0054-A-03-NNNN is a single-axis converter power section for medium-power servo applications. Its 54 A maximum-current class, 20.6 A continuous-current reference and approximately 7.5 kW motor-rating reference support dynamic feeds, material-handling axes, printing equipment and production machinery. The power section connects to a separate CSB or CSH control section, which supplies control performance, communications, encoder interfaces and safety functions. The completed drive is therefore defined by both the HCS02 power hardware and the attached control-section and firmware configuration.

Key Features

• 54 A maximum and 20.6 A continuous current
• Typical 7.5 kW motor class
• 3 AC 200 to 500 V direct mains range
• Higher continuous power when used with the specified choke
• Control-section slot for scalable functionality
• IP20 enclosure with internal air cooling

Typical Applications

• Medium-power packaging machinery
• Woodworking and converting equipment
• Robotic and material-handling axes
• Dynamic 7.5 kW-class servo axes

Supply and Inquiry Information

Supply is verified using HCS02.1E-W0054-A-03-NNNN and material number R911298373. Quote requests should include quantity, destination country, requested condition, delivery target, nameplate photo, choke arrangement and the CSB or CSH control-section code. The offer must state whether it includes only the power section or a complete tested assembly with control section, firmware, connectors and accessories.

FAQ

Q1 Can I request the exact HCS02.1E-W0054-A-03-NNNN for purchase?

Yes. Use the complete model and material number R911298373 in the inquiry. Current availability, condition and lead time are confirmed for the requested quantity.

Q2 What information is required for a formal quotation?

Provide HCS02.1E-W0054-A-03-NNNN, R911298373, quantity, destination country, requested condition, required delivery date and clear nameplate photos. Include the installed firmware and related system codes when available.

Q3 What is included in the quoted scope?

The quotation should list the bare power section or complete assembly with CSB or CSH control section separately. Items not stated in the offer should not be assumed to be included.

Q4 Can a similar HCS model replace this exact unit?

Do not assume that W0028 or W0070 is interchangeable. Match the 54 A current class, dimensions, choke and mains components, motor load, control section, firmware and material number R911298373.

Q5 How are price and lead time determined?

Price and lead time are confirmed after the 54 A HCS02 power section, requested condition, quantity, delivery destination and test scope have been matched to current supply.

Q6 What must be verified before installing the replacement power section?

Compare the complete order code and R911298373, current and mains classes, dimensions, cooling, choke arrangement, motor load, CSB or CSH control section and firmware project.
