HMD01.1N-W0012-A-07-NNNN 12A Double-Axis Inverter

This HMD01 module is a DC-supplied double-axis inverter that generates two independently regulated AC outputs for two motors. It gives a modular IndraDrive M system a space-saving way to control a paired set of axes from one power-section housing while retaining separate motion behavior for each motor.

The 12 A current class is suited to two compact motor axes that can share one narrow power section. It is normally placed on the shared DC bus of an HMV01 or HMU05 supply unit and completed with the control hardware, feedback interfaces, communication and safety functions required by the two-axis application.

Key Features

• Two independently regulated motor outputs in one modular power section
• 12 A maximum-current class with 6.9 A continuous-current reference
• Uses the shared IndraDrive M DC bus for both controlled axes
• Provides a mounting location for the matched double-axis control section
• 50 mm module width for a space-efficient two-axis cabinet layout
• Internal air cooling and IP20 protection for cabinet installation

Typical Applications

• Twin feeder axes
• Compact pick-and-place pairs
• Dual conveyor sections
• Small synchronized machine stations

Supply and Inquiry Information

Supply is handled against the complete order code HMD01.1N-W0012-A-07-NNNN and material number R911306439. For an availability and quotation check, send the required quantity, destination country, requested condition, delivery target and clear photos of the existing nameplate. Include the DC-bus source, both motor models, installed double-axis control section, firmware, communication, feedback and safety configuration. The quotation will define the inverter scope and list control hardware, firmware, connectors and accessories separately.

FAQ

Q1 Can I purchase the exact HMD01.1N-W0012-A-07-NNNN double-axis inverter?

Yes. Quote requests should use the full order code and material number R911306439. Availability, condition, lead time and test scope are confirmed for the requested quantity.

Q2 What information is required for a quotation?

Provide HMD01.1N-W0012-A-07-NNNN, R911306439, quantity, destination, requested condition, delivery target and nameplate photos. Include both motor models, the DC-bus source, double-axis control section, firmware, communication, feedback and safety details.

Q3 What is normally included in the quoted scope?

The quotation should state whether it covers the double-axis inverter power section only. Control hardware, firmware, memory media, connectors, bus accessories and cables are included only when individually listed.

Q4 Can HMD01.1N-W0020-A-07-NNNN replace this model?

It is not an automatic replacement. Match the full order code, R911306439, current class, width, DC-bus source, both motor loads, control section, firmware, interfaces, safety functions and project parameters.

Q5 Can two single-axis inverters replace this double-axis unit?

Only after an engineering review. The cabinet layout, control hardware, DC-bus loading, wiring, safety architecture, firmware and machine project may all change, so the conversion should not be treated as a plug-in swap.

Q6 How are price and lead time determined?

They are checked for the exact HMD01.1N-W0012-A-07-NNNN, requested condition, quantity, destination and test scope. Requirements for matched control hardware, connectors or a replacement engineering review can also affect the quotation.
