AST3501-T1-AF 10.4 Inch TFT HMI 640x480 100-240VAC

Parameters

Product Description

The AST3501-T1-AF is the 100 to 240 V AC version of a 10.4-inch TFT color operator panel with 640 x 480 resolution. It includes two serial ports, a USB Type A host interface and a CompactFlash slot, with 6 MB application memory and 320 KB backup SRAM. The display supports 256 colors without blinking or 64 colors with blinking. Match the original project settings when sourcing a spare, especially where alarm screens use blinking. Confirm the AC nameplate, 259 x 201 mm panel opening, serial wiring and included accessories before arranging shipment.

Supply and Quotation

Request a quotation for AST3501-T1-AF with quantity, destination and required arrival date. Send model-label, revision and connector photos when sourcing a spare. We will confirm the offered condition, availability, installed options, included accessories and delivery terms in the quotation. Software licenses, transfer cables, memory cards and machine programs require separate confirmation.

Compatibility

Use a project and engineering-software version that support AST3501-T1-AF. Verify the display mode, controller driver, serial pinout, supply and mounting dimensions. Confirm the supported transfer cable and access to the original backup. Changing the target panel requires a project review and functional testing.

FAQ

1. What power input does the AF version require?
   The AF reference is rated for 100 to 240 V AC. The D24 reference is a separate 24 V DC model. Verify the actual nameplate, terminal arrangement and cabinet supply before selecting the unit.
2. What color and blink settings should be checked?
   The TFT display supports 256 colors without blinking or 64 colors with blinking. Review the original screen project, including alarm indications and color assignments, before transferring it to the supplied panel.
3. What dimensions should be checked before purchase?
   The nominal panel opening is 259 x 201 mm and external dimensions are 270.5 x 212.5 x 57 mm. Confirm the installation drawing for opening tolerances, panel thickness, gasket, fasteners and cable clearance before ordering or modifying a cabinet.
4. How do I request a price for AST3501-T1-AF?
   Send the full reference, quantity, preferred condition and delivery destination. Include nameplate and revision photos and any deadline. Price and availability are confirmed for the specific offered unit.
5. Will the original machine program be included?
   Confirm access to the project backup, passwords and compatible legacy software before purchase. Hardware supply does not establish that your application is loaded. Agree any transfer, recovery or commissioning work separately.
6. What should be confirmed before shipment?
   Request matching label and connector photos, an accessory list and an agreed inspection scope covering display and touch response. Confirm packaging, dispatch timing, delivery terms and warranty in the quotation.
