6PPT30.057L-20W Power Panel T30 5.7 Inch Portrait HMI

The B&R 6PPT30.057L-20W is a 5.7-inch Power Panel T30 operator terminal with a portrait VGA 480 x 640 pixels display and analog resistive touch input. It combines a 600 MHz ARM Cortex-A8 processor, 256 MB DRAM and 512 MB onboard flash with two Fast Ethernet ports and two USB 2.0 interfaces.

This model is mechanically arranged for portrait mounting with a 140 x 172 mm front and 480 x 640 resolution. It suits tall, narrow control surfaces and should not be confused with the landscape 6PPT30.0573-20W even though the processor, memory and network platform are similar.

Key Features

· 5.7-inch VGA 480 x 640 pixels TFT color display

· Portrait panel format for vertical machine interfaces

· Analog resistive touch screen suitable for gloved operation

· Dual 10/100 Mbit/s Ethernet ports with integrated switch

· Integrated VNC client, web browser and service page

· IP65 front protection and wide -20 to 60°C operating range

Typical Applications

· Vertical operator stations

· Narrow machine columns

· Recipe and alarm lists

· Packaging and filling equipment

· Retrofits requiring a portrait cutout

Compatibility Note

This T30 model is an HMI terminal, not a standalone PLC. Confirm the exact order number, panel cutout, screen orientation, hardware revision and installed image before replacement.

FAQ

Q: Is this Power Panel a standalone PLC?

A: No. It is a terminal-design HMI used as a VNC or web client. Machine control must be provided by a compatible controller.

Q: What touch technology does it use?

A: It uses an analog resistive touch screen, which is suitable for industrial operation and can generally be used with gloves or a stylus.

Q: How many Ethernet ports are available?

A: Two 10/100 Mbit/s Ethernet ports are provided through an integrated switch for convenient line wiring.

Q: Does it support both VNC and web visualization?

A: Yes. The terminal includes a VNC client, an embedded web browser and an integrated service page.

Q: Can the landscape 0573 model replace this portrait panel?

A: Not as a direct mechanical replacement. The screen orientation, front dimensions and installation cutout differ even though the display diagonal and core electronics are related.

Q: Can a similar T30 model be used as a direct replacement?

A: Not automatically. Match the full model number, screen format, cutout dimensions, front design, hardware revision and software image before replacement.
