6PPT50.0702-16A Power Panel T50 7 Inch Dual Ethernet HMI

The B&R 6PPT50.0702-16A is a 7.0-inch Power Panel T50 HMI terminal built around an 800 MHz dual-core ARM Cortex-A9 platform with 1 GB DRAM and 512 MB onboard flash. Its WVGA 800 x 480 pixels projected-capacitive display supports multi-touch operation through a chemically hardened anti-glare glass front.

The -16A configuration is distinguished by two Gigabit Ethernet ports with an integrated switch. Compared with the 6PPT50.0702-10A, it supports direct Ethernet line topology without adding an external switch while retaining the same 7-inch WVGA display size.

Key Features

· 7.0-inch WVGA 800 x 480 pixels multi-touch display

· Chemically hardened 6H anti-glare glass front

· Dual-core 800 MHz ARM Cortex-A9 processor

· Dual Gigabit Ethernet ports with integrated switch

· Two USB 2.0 ports with 0.5 A capacity each

· VNC client, embedded browser and mapp View support

Typical Applications

· Networked packaging machines

· Distributed operator stations

· Assembly and handling cells

· Production line visualization

· Machines using Ethernet line topology

Compatibility Note

This T50 model is a visualization terminal, not an Automation Runtime machine controller. Verify the full order number, Ethernet variant, panel cutout, hardware revision and PPT50 image when replacing an installed unit.

FAQ

Q: Does this unit run the machine control program?

A: No. The T50 is a terminal-design HMI. It displays visualization content supplied through VNC, web technology or a compatible HMI application.

Q: Does the screen support multi-touch gestures?

A: Yes. It uses projected-capacitive multi-touch technology behind a chemically hardened glass surface.

Q: How many Ethernet ports does this model have?

A: Two shielded Gigabit Ethernet ports are connected through an integrated switch, allowing convenient line wiring.

Q: What does the A suffix indicate on this selected variant?

A: The selected A variant uses an anti-glare glass front. Closely related B variants use a standard glass front.

Q: What is the main difference from 6PPT50.0702-10A?

A: This -16A model has two Gigabit Ethernet ports with an integrated switch. The -10A model has one Gigabit Ethernet port.

Q: Can another T50 size or Ethernet version replace it directly?

A: Not without engineering checks. Screen size, cutout, port count, hardware revision, image version and project configuration must all match the application.
