6PPT50.121E-16A Power Panel T50 12.1 Inch Dual Ethernet HMI

The B&R 6PPT50.121E-16A is a 12.1-inch Power Panel T50 HMI terminal built around an 800 MHz dual-core ARM Cortex-A9 platform with 1 GB DRAM and 512 MB onboard flash. Its WXGA 1280 x 800 pixels projected-capacitive display supports multi-touch operation through a chemically hardened anti-glare glass front.

This model combines a 12.1-inch viewing area with the -16 dual-port Gigabit Ethernet configuration. It offers more physical screen space than the 10.1-inch model while maintaining the same 1280 x 800 resolution and adds convenient network line wiring.

Key Features

· 12.1-inch WXGA 1280 x 800 pixels multi-touch display

· Chemically hardened 6H anti-glare glass front

· Dual-core 800 MHz ARM Cortex-A9 processor

· Dual Gigabit Ethernet ports with integrated switch

· Two USB 2.0 ports with 0.5 A capacity each

· VNC client, embedded browser and mapp View support

Typical Applications

· Large machine dashboards

· Production line overview stations

· Process and batch visualization

· Multi-screen recipe navigation

· Ethernet line-topology machines

Compatibility Note

This T50 model is a visualization terminal, not an Automation Runtime machine controller. Verify the full order number, Ethernet variant, panel cutout, hardware revision and PPT50 image when replacing an installed unit.

FAQ

Q: Does this unit run the machine control program?

A: No. The T50 is a terminal-design HMI. It displays visualization content supplied through VNC, web technology or a compatible HMI application.

Q: Does the screen support multi-touch gestures?

A: Yes. It uses projected-capacitive multi-touch technology behind a chemically hardened glass surface.

Q: How many Ethernet ports does this model have?

A: Two Gigabit Ethernet ports are provided through an integrated switch for line-topology installations.

Q: What does the A suffix indicate on this selected variant?

A: The selected A variant uses an anti-glare glass front. Closely related B variants use a standard glass front.

Q: How does it differ from the 10.1-inch T50?

A: Both can use 1280 x 800 resolution, but this model has a larger 12.1-inch screen and a larger panel cutout. This selected -16A version also has dual Gigabit Ethernet.

Q: Can another T50 size or Ethernet version replace it directly?

A: Not without engineering checks. Screen size, cutout, port count, hardware revision, image version and project configuration must all match the application.
