6PPT50.0702-16B Power Panel T50 7 Inch Dual Ethernet HMI

The B&R 6PPT50.0702-16B is a 7.0-inch Power Panel T50 HMI terminal based on an 800 MHz dual-core ARM Cortex-A9 platform with 1 GB DRAM and 512 MB onboard flash. Its WVGA 800 x 480 pixels projected-capacitive display supports multi-touch operation through chemically hardened 6h standard glass with black frame.

The -16B code combines dual switched Gigabit Ethernet with the standard glass front. It offers easier line-topology wiring than the single-port 6PPT50.0702-10B while keeping the same seven-inch display and enclosure size.

Key Features

· 7.0-inch WVGA 800 x 480 pixels multi-touch display

· Chemically hardened 6H standard glass front

· Dual-core 800 MHz ARM Cortex-A9 processor

· Dual Gigabit Ethernet ports with integrated switch

· Two USB 2.0 ports with 0.5 A capacity each

· VNC client, embedded browser and mapp View support

Typical Applications

· Compact multi-touch operator stations

· Line-topology Ethernet machines

· Packaging and labeling equipment

· VNC and web visualization

· Cabinet retrofits requiring dual network ports

Compatibility Note

This T50 model is a visualization terminal, not an Automation Runtime machine controller. Verify the full order number, glass variant, Ethernet port count, panel cutout, hardware revision and PPT50 image before replacement.

FAQ

Q: Does this unit run the machine control program?

A: No. The T50 is a terminal-design HMI. It displays visualization content supplied through VNC, web technology or a compatible HMI application.

Q: Does the screen support multi-touch gestures?

A: Yes. It uses projected-capacitive multi-touch technology behind a chemically hardened glass surface.

Q: How many Ethernet ports does this exact model have?

A: Two Gigabit Ethernet ports are provided through an integrated switch on this -16B version.

Q: What does the B suffix indicate on this variant?

A: The B suffix identifies the standard glass version. Closely related A variants add an anti-glare surface treatment.

Q: How does it differ from 6PPT50.0702-10B?

A: This -16B model has two Gigabit Ethernet ports with an integrated switch. The -10B model has one Gigabit Ethernet port.

Q: Can another T50 size or interface version replace it directly?

A: Not without engineering checks. Screen size, cutout, glass type, port count, hardware revision, image version and project configuration must all match the application.
