AGP3500-T1-AF 10.4 Inch TFT HMI 640x480 100-240VAC

Parameters

Product Description

The AGP3500-T1-AF is a 10.4-inch TFT color operator panel for a 100 to 240 V AC supply. Its screen resolution is 640 x 480 pixels. Ethernet, two serial ports, two USB host connections and a CompactFlash slot support the interfaces used by compatible machine projects. When sourcing a spare, match the full nameplate reference, communication wiring and panel opening. Confirm the hardware revision and project requirements before transfer. Send label and connector photographs with the enquiry so the offered configuration, condition and included items can be checked against the machine.

Supply and Quotation

Request a quotation for AGP3500-T1-AF with quantity, destination and required arrival date. Send model-label and connector photos when sourcing a spare. We will confirm the offered condition, hardware revision, availability, included accessories and delivery terms in the quotation. Software licenses and machine programs are included only when expressly stated.

Compatibility

Match the full model to the machine supply, communication wiring, panel opening and project requirements. Confirm the project backup, compatible engineering software and firmware. Hardware revision can affect memory or backlight details; check the offered unit before transfer or commissioning.

FAQ

1. How does this model differ from AGP3510-T1-AF?
   Both references use a 10.4-inch TFT display and AC power. AGP3500-T1-AF has 640 x 480 pixels; AGP3510-T1-AF has 800 x 600. Confirm the project target and screen resolution before substituting a model.
2. Are two USB host connections provided?
   Yes. The panel has two USB 1.1 Type A host ports. Check the supported peripheral or transfer method and the required cable. The connector alone does not establish compatibility with every USB device.
3. What mounting dimensions should be checked?
   The nominal panel opening is 259 x 201 mm, with +1/-0 mm tolerance on each dimension. External dimensions are 270.5 x 212.5 x 57 mm. Use the installation drawing to confirm corner radii, panel thickness, gasket, fasteners and cable clearance.
4. How do I request a price for AGP3500-T1-AF?
   Send the complete reference, quantity, preferred condition and delivery destination. Include label photos and any deadline. Price and availability are confirmed for the specific offered unit.
5. Will the machine program already be installed?
   Confirm access to the project backup, passwords and required software before purchase. Hardware supply does not establish that your application is loaded. Agree any transfer or commissioning work separately.
6. What should be confirmed before shipment?
   Request matching model-label and connector photos, the accessory list and an agreed inspection scope. Confirm packaging, dispatch timing, delivery terms and warranty in the quotation.
