AGP3200-T1-D24 3.8 Inch TFT HMI 320x240 24VDC

Parameters

Product Description

The AGP3200-T1-D24 is a compact 3.8-inch TFT color HMI with 320 x 240 pixels and a 24 V DC supply. It has one serial port, Ethernet and one USB host connection. Its 256-color display and small mounting footprint distinguish it from the larger fixed panels. When sourcing a spare, match the full nameplate reference, communication wiring and panel opening. Confirm the hardware revision and project requirements before transfer. Send label and connector photographs with the enquiry so the offered configuration, condition and included items can be checked against the machine.

Supply and Quotation

Request a quotation for AGP3200-T1-D24 with quantity, destination and required arrival date. Send model-label and connector photos when sourcing a spare. We will confirm the offered condition, hardware revision, availability, included accessories and delivery terms in the quotation. Software licenses and machine programs are included only when expressly stated.

Compatibility

Match the full model to the machine supply, communication wiring, panel opening and project requirements. Confirm the project backup, compatible engineering software and firmware. Hardware revision can affect memory or backlight details; check the offered unit before transfer or commissioning.

FAQ

1. How many serial ports are fitted?
   There is one serial port on COM1, supporting RS-232C/422/485 through a male D-Sub 9 connector. There is no separate COM2 port. Confirm the required controller connection before ordering.
2. Does this compact panel have a CompactFlash slot?
   No. A CompactFlash slot is not fitted. The panel has a USB 1.1 Type A host port and Ethernet. Confirm the supported project-transfer method and required cable for the installed application.
3. What mounting dimensions should be checked?
   The nominal panel opening is 118.5 x 92.5 mm, with +1/-0 mm tolerance on each dimension. External dimensions are 130 x 104 x 40 mm. Use the installation drawing to confirm corner radii, panel thickness, gasket, fasteners and cable clearance.
4. How do I request a price for AGP3200-T1-D24?
   Send the complete reference, quantity, preferred condition and delivery destination. Include label photos and any deadline. Price and availability are confirmed for the specific offered unit.
5. Will the machine program already be installed?
   Confirm access to the project backup, passwords and required software before purchase. Hardware supply does not establish that your application is loaded. Agree any transfer or commissioning work separately.
6. What should be confirmed before shipment?
   Request matching model-label and connector photos, the accessory list and an agreed inspection scope. Confirm packaging, dispatch timing, delivery terms and warranty in the quotation.
