B&R X20PS2110 Fused 24VDC I/O Power Supply

Name: B&R X20PS2110 Fused 24VDC I/O Power Supply
Brand: Dengfeng (Zhaoqing) Trading Co., Ltd
SKU: X20PS2110
Availability: InStock

Product Details

Place of Origin: Austria

Brand Name: B&R

Model Number: X20PS2110

Payment & Shipping Terms

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:

Product Family:	X20 System	Module Type:	Fused Internal I/O Power Supply Module
Input Voltage:	24 VDC -15% / +20%	Maximum Input Current:	6 A
Nominal Output Voltage:	24 VDC	Permissible Contact Load:	6 A
Integrated Fuse:	6.3 A Slow-blow, Replaceable	Short-Circuit Protection:	Integrated Fuse
Reverse Polarity Protection:	No	Electrical Isolation:	I/O Supply Not Isolated From Input Power
Bus Power Consumption:	0.2 W	Internal I/O Power Consumption:	0.82 W
Operating Temperature:	-25 To 60°C Horizontal; -25 To 50°C Vertical	Protection Rating:	IP20
Module Pitch:	12.5 Mm	Mandatory Accessories:	X20BM01 Or X20BM05 Bus Module And X20TB12 Terminal Block

Product Family:	X20 System
Module Type:	Fused Internal I/O Power Supply Module
Input Voltage:	24 VDC -15% / +20%
Maximum Input Current:	6 A
Nominal Output Voltage:	24 VDC
Permissible Contact Load:	6 A
Integrated Fuse:	6.3 A Slow-blow, Replaceable
Short-Circuit Protection:	Integrated Fuse
Reverse Polarity Protection:	No
Electrical Isolation:	I/O Supply Not Isolated From Input Power
Bus Power Consumption:	0.2 W
Internal I/O Power Consumption:	0.82 W
Operating Temperature:	-25 To 60°C Horizontal; -25 To 50°C Vertical
Protection Rating:	IP20
Module Pitch:	12.5 Mm
Mandatory Accessories:	X20BM01 Or X20BM05 Bus Module And X20TB12 Terminal Block

Description

B&R X20PS2110 Fused 24VDC I/O Power Supply

The B&R X20PS2110 supplies 24 VDC to the internal I/O contacts of an X20 station and includes a replaceable 6.3 A slow-blow fuse. This integrated protection simplifies identification and servicing of an overloaded I/O potential group.

Its main difference from the X20PS2100 is the onboard fuse. The X20PS2110 is limited to a 6 A contact load, while the unfused X20PS2100 supports up to 10 A with external protection. It does not supply X2X Link bus power.

Key Features

Integrated replaceable 6.3 A fuse
Maximum 6 A I/O current
24 VDC internal I/O supply
Operating-state and module-status diagnostics
Compact 12.5 mm module pitch
Suitable for independently protected I/O groups

Typical Applications

Fused X20 potential groups
Machine I/O branch protection
Distributed control cabinets
Packaging and handling systems
Maintenance-focused automation installations

FAQ

Q: Can the fuse in X20PS2110 be replaced?

A: Yes. The module uses an integrated, replaceable 6.3 A slow-blow fuse.

Q: Can X20PS2110 replace X20PS2100?

A: The electrical design must be checked first. X20PS2110 has integrated protection but permits 6 A instead of the 10 A contact load supported by X20PS2100.

Q: Does the module include X20BM01 and X20TB12?

A: No. The compatible power-supply bus module and terminal block are separate components.
