AGP3302-B1-D24 5.7 Inch Blue Mono HMI 320x240 24VDC

Parameters

Product Description

The AGP3302-B1-D24 is a 5.7-inch blue-mode monochrome HMI with 320 x 240 resolution and 24 V DC input. It provides two serial ports and one USB host port. Built-in Ethernet and a CompactFlash slot are not fitted, making the communication and transfer requirements especially important when sourcing this reference. When sourcing a spare, match the full nameplate reference, communication wiring and panel opening. Confirm the hardware revision and project requirements before transfer. Send label and connector photos so the offered configuration, condition and included items can be checked against the machine.

Supply and Quotation

Request a quotation for AGP3302-B1-D24 with quantity, destination and required arrival date. Send model-label and connector photos when sourcing a spare. We will confirm the offered condition, hardware revision, availability, included accessories and delivery terms in the quotation. Software licenses and machine programs are included only when expressly stated.

Compatibility

Match the full model to the machine supply, communication wiring, panel opening and project requirements. Confirm the project backup, compatible engineering software and firmware. Hardware revision can affect memory or backlight details; check the offered unit before transfer or commissioning.

FAQ

1. Does this model have Ethernet or a CompactFlash slot?
   No. Neither is fitted. Confirm that the machine can use the available serial interfaces and supported transfer method. Do not copy Ethernet or card-slot specifications from another 5.7-inch model.
2. What is unusual about the serial connectors?
   COM1 is RS-232C only. COM2 is RS-422/485. Both use male D-Sub 9 connectors. Verify the signal standard, connector and pinout of each cable before connection.
3. What mounting dimensions should be checked?
   The nominal opening is 156 x 123.5 mm, with +1/-0 mm tolerance on each dimension. External dimensions are 167.5 x 135 x 59.5 mm. Use the installation drawing to check corner radii, panel thickness, gasket, fasteners and cable clearance.
4. How do I request a price for AGP3302-B1-D24?
   Send the complete reference, quantity, preferred condition and delivery destination. Include label photos and any deadline. Price and availability are confirmed for the specific offered unit.
5. Will the machine program already be installed?
   Confirm access to the project backup, passwords and required software before purchase. Hardware supply does not establish that your application is loaded. Agree any transfer or commissioning work separately.
6. What should be confirmed before shipment?
   Request matching model-label and connector photos, the accessory list and an agreed inspection scope. Confirm packaging, dispatch timing, delivery terms and warranty in the quotation.
